Panel PC with touch screen R19IT3S-65M1

5-wire resistive touch screentouch screen19"

Overview
19.0-inch IP65 stainless panel PC with Intel® Core™ i5-1135G7. Fanless design and stainless housing with anti-corrosion treatment for hygienic and washdown environments in food, beverage and pharmaceutical production.

Applications

• Hygienic production lines and washdown areas
• Food processing, beverage plants and pharmaceutical production
• Industrial HMI, machine control and operator stations

Key Features

• Intel® Core™ i5-1135G7 (2.4GHz, up to 4.2GHz)
• Fanless touch-screen monitor with IP65 front
• Stainless steel enclosure with anti-corrosion treatment
• Full dust and water protection (IP65)
• Optical bonding with anti-moisture treatment (optional)
• 5-wire resistive touch or protection glass (optional)

Certifications

• IP65
• CE
• FCC

Display

• Size: 19.0 inches
• Resolution: 1280 x 1024
• Brightness: 250 nits
• Contrast ratio: 1000:1
• Viewing angles: 85/85/80/80
• Active area: 376.32 x 301.06 mm
• Touch / Glass: 5-wire resistive (optional) or protection glass without touch (optional)

System Specification

• Processor: Intel Core i5-1135G7 (2.4GHz, up to 4.2GHz)
• Memory: 4GB default; optional 8GB / 16GB / 32GB
• Storage: 128GB SSD default; optional up to 4TB; 1 x SATA III for 2.5" SSD/HDD up to 2TB (optional)
• Ethernet: 2 x Intel® Ethernet controllers
• Security: TPM 2.0
• OS: Optional Windows 11 IoT Enterprise / Windows 11 Pro / Linux Ubuntu 22.04 (Wake on Touch not supported on Linux)
• Optional: WLAN and Bluetooth

Mechanical

• Dimensions: 468 x 395 x 63 mm
• Mounting: VESA mount standard; yoke mount optional
• Enclosure: Stainless housing
• Cooling: Fanless design

Environment

• Operating temp: 0°C to 45°C
• Storage temp: -20°C to 60°C
• Operating humidity: 10% to 90% RH, non-condensing
• IP rating: IP65

IO Ports

• USB: 1 x M12 waterproof connector for 2 x USB2.0
• Serial: 1 x M12 waterproof connector for RS232
• LAN: 1 x waterproof Gigabit RJ45 connector
• Indicators: LED for power; LED for storage activity

Control

• Buttons: 1 x Power; 1 x Reset

Accessories

• 100~240V AC-to-DC adapter with waterproof connector (included/optional)
• Power cord; external USB/COM/LAN cables with waterproof connectors; waterproof caps; manual; VESA screws

Power

• Power input: 12V DC (M12 type)

Technical specifications

• Model: R19IT3S-65M1
• Brand: Winmate
• CPU: Intel® Core™ i5-1135G7
• Display: 19.0", 1280 x 1024, 250 nits
• Touch: 5-wire resistive (optional) / protection glass (optional)
• Memory: 4GB default, up to 32GB optional
• Storage: 128GB SSD default, up to 4TB optional
• Protection: Stainless housing, IP65 front, waterproof connectors
