Steel conveyor chain

linkfor the food industrycorrosion-resistant

Introduction
TopOne Chain's Egg Conveyor Chain is engineered for automated poultry farming to transport eggs gently and reliably from laying nests to central collection points. Manufactured from high-grade steel with case hardening and a 25 µm electro-galvanized finish, the chain is dimensionally controlled and tested for use in humid, ammonia-prone poultry house environments.

Chain Applications

• Automated egg collection systems
• Poultry farm conveyor lines
• Egg handling and transport equipment

Chain Specifications
Wire diameter (dn): 6 mm (± 0.1 mm)
Inner pitch (t): 32.2 mm (+0.1 / -0.1 mm)
Outside width (b2): 22 mm (max)
Approximate weight: 0.65 kg/m

Connecting Link Specifications
Dimension: 6 x 32.2 mm
Outside width: 22 mm (max)
Breaking force: 30 kN (min)

Quality & Finishing Standards
Surface hardness: 800 HV10 minimum
Hardness depth: 0.56 mm (0.07 × wire diameter)
Limit hardness: 550 HV1
Finish: 25 µm electro-galvanizing

Additional Product Details
High-grade material: special steel wire selected for tensile strength and durability.
Advanced hardening: case-hardening for a wear-resistant surface with a ductile core to absorb shock loads.
Corrosion protection: 25 µm electro-galvanized coating for resistance to ammonia and high humidity.
Quality testing: each batch inspected for dimensional accuracy, hardness and breaking force.
MOQ: 500 meters
Package: Wooden box or steel pallet

Technical Specifications

• Product: Egg Conveyor Chain
• Wire diameter: 6 mm (± 0.1 mm)
• Pitch (inner): 32.2 mm (+0.1 / -0.1 mm)
• Outside width: 22 mm (max)
• Approx. weight: 0.65 kg/m
• Connecting link dimension: 6 x 32.2 mm
• Connecting link breaking force: ≥ 30 kN
• Surface hardness: ≥ 800 HV10
• Hardness depth: 0.56 mm (0.07 × wire diameter)
• Limit hardness: 550 HV1
• Finish: 25 µm electro-galvanizing
• MOQ: 500 meters
• Packaging: Wooden box or steel pallet
