Synchronous servomotors

... are available in three performance classes with a continuous torque of 76 to 160 mNm. The drives comprise a brushless DC-Servomotor, a high-resolution actual value encoder and a Motion Controller in a complete, compact ...

Rotational speed: 5,600, 5,700, 6,400, 7,100, 11,400 rpm
Diameter: 22, 32 mm

From dynamic start/stop operation to speed control and highprecision, integrated position control in confined installation spaces – the flexible BX4 modular system can be combined with a wide variety of gearhead and lead screw attachments ...

Rotational speed: 6,100 rpm - 62,400 rpm

Brushless DC-Servomotors FAULHABER Brushless DC-Servomotors are designed for demanding applications where compact size and high performance are key. They are available in high torque 4-Pole or high ...

Torque: 0.75 Nm
Power: 125 W - 250 W
Rotational speed: 3,000 rpm

EN: Brushless servomotors with integrated drive. Power from 125 to 250 W USA: Brushless servomotors with integrated drive. Power from 1/6 to 1/3 HP MOTOR: Brushless 4-pole three-phase sinusoidal motor, ...

Torque: 1.5 Nm
Power: 500 W

Ever since it entered the market, Mini Motor’s family of brushless servomotors with integrated drive has set a new standard of productive excellence in terms of rationalization, integration and performance, distinguishing ...

Torque: 0.085 Nm - 0.165 Nm
Power: 32 W - 61 W
Rotational speed: 4,000 rpm

EN: 4-pole sinusoidal brushless motor with resolver. Power from 32 to 61 W. Rated torque from 0,085 to 0,165 Nm. Ø 35 mm. USA: 4-pole sinusoidal brushless motor with resolver. Power from 1/23 to 1/12HP. Rated torque from 0.752 to 1.46 ...

Torque: 0.159 Nm - 27.7 Nm
Power: 50 W - 750 W
Rotational speed: 0 rpm - 5,500 rpm

For AC-Input (NX) NX Series AC-Servomotor Features Easy handling Auto-tuning function IP65

Torque: 0.4 Nm - 11.5 Nm
Power: 0.7 kW - 11 kW
Rotational speed: 7,000 rpm - 17,000 rpm

... version on request Applications: • Tooling Machines Technical Overview: • Motor Technology : permanent magnet synchronous servo motor • Frame Sizes : 60mm | 80mm | 110mm | 130mm • Power Range ...

Torque: 0.9 Nm - 26.7 Nm
Power: 314, 384, 698, 620, 1,535 W
Rotational speed: 3,000, 6,000, 5,200 rpm

Available in 60-100mm frame sizes, Motornet DC servo motors have the drive/controller electronics integrated inside the motor - making them ideal for use in multi-axis decentralized applications where numerous motors ...

Torque: 0.19 Nm - 60 Nm
Power: 0.1 W - 9.4 W
Rotational speed: 0 rpm - 7,500 rpm

... brushless servo motors have been designed to combine cutting-edge technology with extremely high performance. Utilising innovative ‘Salient Pole' technology, featuring Neodymium-Iron-Boron magnets uniquely encapsulated ...

The right servo motor for every application The PMCtendo servo motor can be used in any application. Regardless of whether your focus is on dimensions, dynamics, controllability or the feedback systems. ...

Torque: 0.318 Nm - 52.9 Nm
Power: 100 W - 5,500 W
Rotational speed: 3,000, 5,000, 6,000, 2,000 rpm

With the help of AC Servo Motors the functionality of positioners can be increased and furthermore additional applications are possible. A flexible solution from Panasonic! The AC-Servo Motors are free programmable and ...

Torque: 0.32 Nm - 0.96 Nm
Power: 100 W
Rotational speed: 3,000, 5,000 rpm

BSD-FAL01AM8N-2 Servo motor 230 VAC, 100 W 40mm flange, 8mm shaft, 0.32/0.96Nm, 3000/5000rpm Absolute 18 bit multi turn encoder (262144 ppr) Low inertia

Torque: 0.64, 1.91 Nm
Power: 200 W
Rotational speed: 3,000, 5,000 rpm

BSD-FBL02AMK-2 Servo motor 230 VAC, 200 W 60mm flange, 14mm shaft, 0.64/1.91Nm, 3000/5000rpm Absolute 19 bit multi turn encoder (524288 ppr) Low inertia

Torque: 1.27 Nm
Power: 400 W
Rotational speed: 3,000, 5,000 rpm

BSD-FBL04AMK-2 Servo motor 230 VAC, 400 W 60mm flange, 14mm shaft, 1.27/3.82Nm, 3000/5000rpm Absolute 19 bit multi turn encoder (524288 ppr) Low inertia

Power: 30 W - 25,000 W

Compact and reliable servo motors with middle inertia: High efficiency and et stable holding torque Flange size: 40mm, 60mm, 80mm, 86mm, 100mm, 130 mm, 180mm, 220mm and 275mm square Rated power: 30W to 30kW ...

Power: 30 W - 200 W

Flange size: 20mm, 40mm and 60mm square Rated power: 20W to 200W Maximum speed: 6000tr/min Sensor: absolute or 17-bit (131072 PPR) incremental encoder IP rate: IP67 Options : Holding brake

Power: 500 W - 5,500 W

Flange size: 100mm to 180mm square Rated power: 500W to 5.5kW Maximum speed: 6000tr/min Sensor: Battery-less absolute encoder (17 bit standard) IP rate: IP67 Option : Holding brake

Torque: 2.7 Nm - 36 Nm

iBMD can be controlled by a master or in standalone mode. It reduces in both cable and electrical cabinet costs. Reducing the total unit size by more than 35% compared to a classical servo drive solution.

Torque: 1.4 Nm - 410 Nm
Rotational speed: 1,000 rpm - 6,000 rpm

Emerson Industrial's Unimotor FM is perfect for wrapping, dosing, printing, conveying and winding. This is recognized for its mechanical flexibility because consumers have the option with regard to its speed, sensors, inertia and mechanical ...

Torque: 0.7 Nm - 255 Nm
Rotational speed: 1,000 rpm - 6,000 rpm

The Unitmotor HD is a servomotor equipped with dynamics for ephemeral cycles. It has an optimum performance through its wide options of speed and position. It has an ultra-compact design that comes with a low inertia. ...

Power: 50 W - 750 W

24-bit high-resolution encoder installed High efficiency, low heat generation Downsizing by up to 20% Flange compatible with Sigma-5 Medium inertia, high speed

Power: 300 W - 15,000 W

24-bit high-resolution encoder installed High efficiency, low heat generation Downsizing by up to 20% Flange compatible with Sigma-5 Medium inertia, large torque

Torque: 0.159 Nm - 8.36 Nm
Power: 50 W - 750 W
Rotational speed: 0 rpm - 6,000 rpm

SGMJV Model Features Medium inertia, small capacity Instantaneous peak torque (350% of rated torque) Mounted high-resolution serial encoder: 13 bit or 20 bit Application Examples: Semiconductor equipment ...

Torque: 0.16 Nm - 28.7 Nm
Power: 50 W - 5,000 W
Rotational speed: 3,000, 2,000, 1,000 rpm

IP67 degree of protection (Not featured in the MSMD, MHMD type) Features enhanced durability in harsh industrial environments. The MINAS A5’s improved motor seals, the direct-mount connectors in the motor power supply, and the encoder ...

Torque: 0.16 Nm - 14.3 Nm
Power: 50 W - 1,000 W
Rotational speed: 3,000, 2,000 rpm

HIWIN servo motors HIWIN synchronous AC servo motors are available with power from 50 to 1,000 W. The standard motors are equipped with an absolute encoder (17 bit singleturn or multiturn), ...

Torque: 1.1, 2.15, 3.2 Nm
Rotational speed: 2,000, 750, 1,000 rpm

The decentralized compact servo drives have additional benefits compared to the servo amplifiers which are located in the centralized cabinets. These advantages are smaller cabinet, less cabeling effort, minimization of the error sources, ...

Torque: 3.3 Nm
Power: 230 W
Rotational speed: 2,000 rpm

The ECOMPACT® 100 is a decentral servo drive with an integrated servo amplifier. The modular design of the device enables rapid customer-specific adaptation. Options such as, sensorless operation, holding brake, connection of an internal ...

Torque: 0.89, 1.22, 1.08, 0.56 Nm
Rotational speed: 5,000, 6,000, 7,700, 8,000 rpm
Diameter: 60 mm

The ECOSPEED® Series, manufactured by Jenaer Antriebstechnik, is a low-pole brushless AC electric servo-motor. The torque level is from 1-26 NM. The flange is available in the dimensions 60mm, 80mm, 110mm and 130mm. The ...

Torque: 0.318 Nm
Power: 100 W
Rotational speed: 3,000 rpm

SERVO MOTOR WITH BRUSHLESS DRIVE - EC 40 | 60 | 80 (AC) SKU 474xxx xxxx Delivery Time 2 weeks Features brushless small & compact maintenance-free Protection IP65

Torque: 0.637 Nm
Power: 200, 400 W
Rotational speed: 3,000 rpm

Isel's EC 60 Series of high-performance brushless AC electric servo-motors are electronically commutated 3-phase motors, integrated with brushless drives. These motors feature comprehensive output performance levels, ...

Torque: 2.39 Nm
Power: 750 W
Rotational speed: 3,000 rpm

SERVO MOTOR WITH BRUSHLESS DRIVE - EC 40 | 60 | 80 (AC) SKU 474xxx xxxx Delivery Time 2 weeks Features brushless small & compact maintenance-free Protection IP65

Torque: 0.43 Nm - 5.5 Nm
Power: 150 W - 1,950 W
Rotational speed: 3,000 rpm - 6,000 rpm

The market is increasingly demanding for drive solutions with high acceleration torques respectively a very dynamic behaviour. To sectors like automation and robotics, also the compactness of the motors is of vital importance. In order ...

Torque: 0.12 Nm - 66 Nm
Power: 50 W - 14,000 W
Rotational speed: 3,000 rpm - 9,000 rpm

The servomotors of the HeiMotion Premium series are able to meet the most demanding requirements on the market. The servomotors are available in seven different flange sizes (40mm, 60mm, 80mm, 100mm, ...

Torque: 0.6 Nm - 14.4 Nm
Power: 200 W - 3,000 W
Rotational speed: 2,000 rpm - 3,000 rpm

Our HeiMotion Compact series of brushless AC servo motors includes eight powerful servo motors and 2 matching motion controller families, equipped with different functionalities. Depending on the motor ...

Torque: 0.0651 Nm - 75.2 Nm
Power: 0.3 kW - 10 kW

... installed size. The new generation of synchronous servo motors, announced at the end of September 2017, initially features six design sizes with performance levels between 0,3 and 10 kW. The AKM2G servo motors ...

Torque: 0.409 Nm - 668 Nm
Power: 300 W - 19,500 W
Rotational speed: 0 rpm - 8,000 rpm

Kollmorgen AKM™ servo motors give you unprecedented choice and flexibility, with more than 500,000 standard products and practically unlimited co-engineered modifications. Selecting the right-fit motor—optimized for your ...

Torque: 0.18 Nm - 4.1 Nm
Power: 38 W - 300 W
Rotational speed: 2,000 rpm - 4,500 rpm

... durability, power density, overload capability: KOLLMORGEN has now transferred these four benefits of permanent-excited servo motors to the extra low voltage world. Low voltage servo axes can be used for upgrading existing ...

Torque: 9.6 Nm
Power: 15 kW
Rotational speed: 15,000 rpm

Product Feature 1.Suitable for the 15000rpm high speed 2.Reserve a large margin of security 3.High power & high torque 4.High efficiency 5.Small size 6.Low noise low vibration 7.The autonomous patented cooling structure Specifications Model ...

Torque: 3.8 Nm - 11.4 Nm
Power: 0 W - 1,140 W
Rotational speed: 0 rpm - 3,600 rpm

MAC1200 - The complete solution for medium power ratings. With built-in mains power supply. Choose between model with or without brake. Also in IP66 version. Choose Expansion module from the extensive selection for any application.

Torque: 0.11 Nm - 0.48 Nm
Power: 46 W - 134 W
Rotational speed: 4,000 rpm

The MAC series is an integrated servo motor that is ideal for use in a wide variety of applications with low power ratings ranging from 50 W up to 141 W. There are models of the unit with a protection rating of IP 67. ...

Torque: 1.3 Nm
Power: 400 W
Rotational speed: 3,000 rpm

The Mac400 is an integrated servo motor which is suitable for medium power ratings. The motor comes in two models: one with a brake and another without it. An IP66 version of the motor is also available. The motor ...

esiMot SL: The all-in-one brushless servo drive with three-phase 400V power supply offers high variability and good integration capability through the existing inputs and outputs as well as its comprehensive functionality. Integrated ...

Torque: 0.22 Nm - 7 Nm
Power: 120 W - 2,800 W
Rotational speed: 1,600 rpm - 6,000 rpm

The esiMot series is a brushless DC electric servo-motor with integrated motion controller. This series has a power range from 120 up to 600 watts. This is characterized to have integrated positioning, an speed-/torque ...

Power: 800 W - 3,200 W

The Esimot XL series is manufactured by Esitron, and is a decentralize drive which has a brush-less servo motor that is incorporated with electronics. It also has a speed-/torque regulator with digital 4-Q-regulator. The ...

Torque: 0.15 Nm - 1.2 Nm
Power: 50 W - 400 W
Rotational speed: 3,000, 1,500, 6,000 rpm

A custom engineered solution to satisfy all demands for quick and simple cabling added to a first-in-class performance to size ratio. Mack Tron motor with integrated drive is the ideal solution for decentralized application architectures. Ultra ...

Torque: 1.1 Nm - 7.5 Nm
Rotational speed: 3,000, 2,200 rpm

Brushless integrated servomotor with built-in servodrice, torques from 1.1 to 7.5 Nm and 220Vac single or three phase power supply. Quick and easy cabling, installation and configuration, maintaining the Axor’s typical ...

Torque: 0.16, 0.32, 0.65, 1.3 Nm
Power: 50, 100, 200, 400 W
Rotational speed: 3,000, 1,500 rpm

A very robust, high performance, low noise motor for DC voltage supplies. Engineered & designed to meet axis control applications up to 1.3Nm. Compact dimensions and long-term reliability. 8 Pole, no cogging B.E.M.F. sine wave ...

... carriages, dual-crowns angular-contact ball bearings with 60° angular capabilities in the precision class P4, and synchronous servomotors complete with permanent magnets (integrated into the hollow shafts). ...

... electric servo-motor manufactured by Unipower, is made with a simple design and characterized with a long-life and high-control service. This device is equipped with a wide range of items that are the electrical oil, ...

Servo motor first feature is to provide electrical oil enables water protection and next cable helps to relieve stress. Thirdly, servo motor shaft ends load and Fourth is most important that servo motor ...

Torque: 0.098 Nm - 3.185 Nm
Power: 30 W - 1,000 W
Rotational speed: 4,500 rpm

The P50B series motors are available with nominal torques ranging from 30W to 1kW. Small size and high rigidity. Their rotation is smoothl even at low speed. Thanks to a rotation speed of 4500 rpm, the positioning time is very short. ...

The ISD series is manufactured by CMZ, and is an integrated step-less drive which consists of 2 phases high torque synchronous motor, full digital servo-drive, encoder and field bus communication. It has a power rating ...
