Differential residual current circuit breaker 03454

residual currentACsingle-pole

Presentation : Residual-current device designed to protect personnel against direct contact and earth leakage faults. Compliant with EN 61008-1, suitable for residential, commercial and industrial electrical distribution where Type AC detection is required.

Reference : REF. 03454

Accessories :

• Power supply kit ID4/12 Dpn 63A
• Copper busbar Tetra 63A 56 modules
• Copper busbar Tetra 63A 12 modules

Technical specifications :

• Function: Residual (earth leakage) protection
• Rated operational voltage (Ue): 240 Vac
• Number of poles: 1P+N
• Rated current: 63 A
• Type: AC
• Residual sensitivity: 300 mA
• Standard: EN 61008-1
• Weight: 0.400 kg
