Steel Rest pad CC-F

Product Overview
Made from solid carbide for high wear resistance. Can be brazed or bonded in jigs, fixtures and clamps. The bottom is chamfered for clearance in the mounting pocket.

Product Types

• CC — Solid carbide
• CRP — Carbide tipped, tapped
• CSRP — Stainless steel, tapped
• CSRP-C — Stainless steel, c'bore
• DRP — Delrin, tapped
• DRP-C — Delrin, c'bore
• SRP — Steel, tapped
• SRP-C — Steel, c'bore

Parts / Options

• CC-1F (SKU 101626) — D: 1/4 in; H: 1/8 in; F x45°: 0.02 in
• CC-2F (SKU 101655) — D: 5/16 in; H: 1/8 in; F x45°: 0.02 in
• CC-3F (SKU 101682) — D: 3/8 in; H: 1/8 in; F x45°: 0.02 in
• CC-4F (SKU 101776) — D: 1/2 in; H: 1/8 in; F x45°: 0.02 in
• CC-5F (SKU 101799) — D: 5/8 in; H: 1/8 in; F x45°: 0.02 in
• CC-6F (SKU 101818) — D: 3/4 in; H: 1/8 in; F x45°: 0.02 in
• CC-8F (SKU 101845) — D: 1 in; H: 5/32 in; F x45°: 0.02 in

Media / Supporting Documents

• Gripper Technical Information (PDF)

Characteristics / Technical specifications

• Material: Solid carbide (high wear resistance)
• Mounting: Can be brazed or bonded in jigs, fixtures and clamps
• Bottom: Chamfered for clearance in mounting pocket
• Units shown on page: Inch
• Typical face relief (F x 45°): 0.02 in for listed CC-F sizes
• Available part numbers and sizes: CC-1F — D 1/4 in, H 1/8 in; CC-2F — D 5/16 in, H 1/8 in; CC-3F — D 3/8 in, H 1/8 in; CC-4F — D 1/2 in, H 1/8 in; CC-5F — D 5/8 in, H 1/8 in; CC-6F — D 3/4 in, H 1/8 in; CC-8F — D 1 in, H 5/32 in
