2-drawer tool cabinet 8002

2-drawer tool cabinet - 8002 - RAU
2-drawer tool cabinet - 8002 - RAU
2-drawer tool cabinet - 8002 - RAU - image - 2
2-drawer tool cabinet - 8002 - RAU - image - 3
2-drawer tool cabinet - 8002 - RAU - image - 4
2-drawer tool cabinet - 8002 - RAU - image - 5
Add to favorites
Compare this product

Characteristics

Number of drawers
2-drawer

Description

Product description
  • Beech solid worktop, thickness 40 mm.
  • Beech slat with finger-joint lamination. Front edge radiused, other edges chamfered.
  • Surface protection with eco-friendly lacquer-oil. 100% in-house production using PEFC-certified raw material from sustainable/regional forestry.
  • System underframe, W1495 x D650 x H840 mm.


Frame / Chassis
  • 4-leg welded frame with two pairs of frame feet made from profile steel tube (45x45x2 mm) including depth braces (top and bottom).
  • Frame feet with end caps including anti-slip studs for secure standing.
  • Under-mounted mobile chassis with eccentric lever (right); operation of the eccentric lever only possible up to a maximum load of 300 kg. Chassis retractable and extendable.
  • Chassis fitted with 2 fixed and 2 swivel castors (wheel diameter 100 mm, overall height 125 mm). Tread made of thermoplastic rubber (non-marking, 85° Shore), wheel body made of polypropylene.
  • Fixed castors on the left, swivel castors on the right (wheel plate mounting).
  • Cross braces from C-profile (40x40x2 mm) under the worktop (front, rear) and a bottom storage shelf (depth 650 mm, rear flush with system underframe, compartment height 580 mm).


Drawers / Equipment
  • 2 under-mount drawers, W520 x D650 x H175 mm with the following layout:
  • 1 x drawer size L 1xH150 mm (internal W490 x D560 mm, load capacity 50 kg).
  • Roller-mounted slides (90% extension). Effective drawer height corresponds to front height minus 15 mm. Drawer tub completely closed to accommodate drawer divider sets optimally.
  • Continuous, fully integrated handle strip (handle edge).
  • Central locking (pin-cylinder lock with 2 keys).


Additional
  • Sliding handles (supplied loose).
  • Extension type: partial extension 90%.


Technical specifications
  • Width: 1500 mm
  • Depth: 700 mm
  • Height: 880 mm
  • Top type: beech solid worktop
  • Top thickness: 40 mm
  • Number of drawers: 2
  • Extension type: partial extension 90%
  • Surface load (mobile): 450 kg
  • Surface load (stationary): 1250 kg
  • Mobility: lowerable/retractable chassis
