7-drawer workshop cart 05-LL5.12.12I-M.11

7-drawer workshop cart - 05-LL5.12.12I-M.11 - RAU
7-drawer workshop cart - 05-LL5.12.12I-M.11 - RAU
7-drawer workshop cart - 05-LL5.12.12I-M.11 - RAU - image - 2
7-drawer workshop cart - 05-LL5.12.12I-M.11 - RAU - image - 3
Add to favorites
Compare this product

Characteristics

Number of drawers
7-drawer

Description

Product description
  • Cabinet with melamine-faced chipboard worktop (approx. 19–20 mm) and black melamine direct coating; splash-proof and stain-resistant surface. Surface properties per EN14322/EN14323: Abrasion resistance Class 3A; scratch resistance N>1.5; stain resistance ≥3; cigarette burn rating 3; steam resistance 4.
  • Core: chipboard to EN309/EN312 (emission class E1) with light grey antistatic ABS edging. Cover material rated normally flammable (B2) per DIN4102. Migration certificate available for food-related use.


Features
  • Left: 1 wing door size L x H720 mm with 1 adjustable shelf behind.
  • Right: 1 wing door size L x H720 mm with 1 adjustable shelf behind.
  • Wing doors with self-closing spring hinges, 180° opening.
  • Continuous integrated handle profile.
  • Central lock: pin cylinder lock with 2 keys.
  • Wheels: 2 rigid castors and 2 swivel castors with brake, mounted on welded wheel plates; wheel diameter 125 mm, overall height 150 mm; tread thermoplastic rubber (grey, non-marking, 85° Shore); wheel core polypropylene.
  • Push handle mounted on the right side, projecting 135 mm.
  • Document pocket B325×T55×H200 mm. Front panel with square-hole system (10×10 mm holes, 38 mm hole centre spacing) for perforated panel accessories.


Technical data
  • Width: 1145 mm
  • Height: 970 mm
  • Depth: 650 mm
  • Worktop type: Melamine top, thickness approx. 19–20 mm
  • Movable surface load: 450 kg


Product data
  • Brand: RAU
  • Model/Reference: Montagewagen BASIC-7
  • EAN: 4040376198938
  • Manufacturer item number: 05-LL5.12.12I-M.11
