1-drawer tool cabinet 8461 BASIC

1-drawer tool cabinet - 8461 BASIC - RAU
1-drawer tool cabinet - 8461 BASIC - RAU
1-drawer tool cabinet - 8461 BASIC - RAU - image - 2
1-drawer tool cabinet - 8461 BASIC - RAU - image - 3
1-drawer tool cabinet - 8461 BASIC - RAU - image - 4
1-drawer tool cabinet - 8461 BASIC - RAU - image - 5
Add to favorites
Compare this product

Characteristics

Number of drawers
1-drawer

Description

Product description
  • Beech solid worktop, 40 mm thickness.
  • Beech lamella with finger-joint bonding. Front edge rounded, other edges chamfered. Surface protected with environmentally friendly lacquer oil. Classic worktop: load-bearing, pressure-resistant, durable, natural, wear-resistant and reusable. 100% in-house production (from tree to worktop) using PEFC-certified raw material from sustainable regional forestry.
  • System substructure dimensions: W1235 x D650 x H840 mm.
  • 4-leg welded frame with two pairs of frame feet made from profile steel tube (45x45x2 mm) including depth braces (top and bottom). Bottom of frame feet fitted with end piece including anti-slip studs for secure standing. Under-mounted retractable chassis with eccentric lever (right side). Operation of the eccentric lever permitted only up to a load of max. 300 kg. Chassis can be engaged and retracted using the eccentric lever. Chassis fitted with 2 fixed and 2 swivel castors (wheel diameter 100 mm, overall height 125 mm, tread made of thermoplastic rubber (non-marking, 85° Shore), wheel body polypropylene).
  • Sliding handles (supplied loose).


Equipment
  • 1 double underframe container, W1145 x D650 x H620 mm with the following layout:
  • left: 1 x shelf-L (height adjustable)
  • right: 1 x drawer size L 1xH180 mm, 1 x hinged door size L 1xH360 mm
  • Drawer size L (internal W490 x D560 mm, load capacity 100 kg). Roller-mounted partial extension rails (90%) with self-insertion and anti-return. Usable drawer height corresponds to front height minus 15 mm. Drawer body fully closed to optimally accept drawer divider sets.
  • Hinged doors with self-closing spring hinges, opening angle 180°.
  • Continuous, fully integrated handle rail (grip edge).
  • Central locking (pin cylinder lock with 2 keys).


Technical specifications
  • Extension type: Partial extension 90%
  • Width: 1500 mm
  • Depth: 700 mm
  • Height: 880 mm
  • Top type: Beech solid worktop
  • Top thickness: 40 mm
  • Number of drawers: 1
  • Drawer (internal): W490 x D560 mm
  • Drawer load capacity: 100 kg
  • Surface load mobile: 450 kg
  • Surface load stationary: 1250 kg
  • Mobility: Lowerable chassis (with eccentric lever, operation up to max. 300 kg)
  • Frame: Profile steel tube 45x45x2 mm
  • Castor data: 2 fixed + 2 swivel castors, wheel diameter 100 mm, overall height 125 mm, tread thermoplastic rubber (non-marking, 85° Shore), wheel body polypropylene
  • System substructure dimensions: W1235 x D650 x H840 mm
