3-drawer workshop cart 05-LL3.0.8I-M.11

Description

• Mobile assembly trolley with upper cabinet and worktop finished with black melamine resin coating (top/bottom). Worktop thickness 20 mm (datasheet: 19 mm). Splash-proof and stain-resistant. Surface properties according to EN14322/EN14323. Core: chipboard EN309/EN312 (emission class E1). Light grey antistatic ABS edging all around.

Equipment

• Left: 3 drawers (front height H180 mm)
• Right: 1 hinged door (H540 mm) with 1 height-adjustable shelf behind
• Drawer interior: W490 x D560 mm, load capacity 100 kg; usable height = front height − 15 mm
• Roller-mounted partial extension slides (90%) with self-closing and anti-rebound
• Hinged doors with self-closing spring hinges, 180° opening
• Continuous integrated handle profile
• Central locking: pin cylinder lock with 2 keys
• 2 fixed and 2 swivel castors with brakes, Ø 125 mm, overall height 150 mm; tread thermoplastic rubber (grey, non-marking, 85° Shore); wheel body polypropylene; mounted on welded wheel plates
• Push handle on right side, projection 135 mm
• Document pocket W325 x D55 x H200 mm; front with square-hole system (10 x 10 mm, hole center distance 38 mm)

Technical data
Width: 1145 mm
Mobile load capacity (drivable surface): 450 kg
Height: 790 mm
Number of drawers: 3
Depth: 650 mm
Worktop type: melamine-top
Worktop thickness: 19 mm


Product details

• Brand: RAU
• Model: Montagewagen BASIC-7
• EAN: 4040376198891
• Article no.: 05-LL3.0.8I-M.11
• Dimensions (W x H x D): 1145 x 790 x 650 mm
• Worktop construction: melamine resin coating (top/bottom black), core chipboard EN309/EN312 (E1)
• Delivery condition: assembled
• Lead time: approx. 15 working days
• Special features: splash-proof, stain-resistant, suitable for food area (migration behaviour tested); normally flammable B2 according to DIN 4102
