2-drawer tool cabinet 8181 BASIC

2-drawer tool cabinet - 8181 BASIC - RAU
2-drawer tool cabinet - 8181 BASIC - RAU
2-drawer tool cabinet - 8181 BASIC - RAU - image - 2
2-drawer tool cabinet - 8181 BASIC - RAU - image - 3
Add to favorites
Compare this product

Characteristics

Number of drawers
2-drawer

Description

Description
  • Beech solid worktop, 40 mm thickness. Finger-jointed beech lamellas. Front edge radiused, other edges chamfered. Surface protection with eco-friendly lacquered linseed oil. Solid beech top produced in-house from PEFC-certified regional raw material.
  • System underframe: W1245 x D650 x H840 mm.
  • Sliding handles supplied loose.


Mobile base / chassis
  • 4-leg welded frame with two pairs of profile steel tube feet (45x45x2 mm) including depth bracing (top and bottom).
  • Retractable chassis operated by eccentric lever (right side). Eccentric lever operation permitted up to a maximum load of 300 kg. Chassis can be extended and retracted with the eccentric lever.
  • Chassis fitted with 2 fixed and 2 swivel castors; wheel diameter 100 mm, overall height 125 mm; tread made of thermoplastic rubber (non-marking, 85° Shore); wheel body polypropylene. Fixed castors mounted on the left, swivel castors on the right (wheel plate mounting).
  • Lower shelf (depth 650 mm, flush with rear of system underframe), compartment height 620 mm.


Equipment / accessories (excerpt)
  • 1 left underframe container, W330 x D650 x H620 mm with 1 sliding door and 1 vice (jaw width 120 mm) with folding lift.
  • 1 right underframe container, W580 x D650 x H620 mm with 1 large drawer (H180 mm) and 1 hinged door (H360 mm).
  • Drawer size L: internal W490 x D560 mm, load capacity 100 kg; partial-extension ball-bearing slides (90% extension) with self-return and anti-rebound; fully enclosed drawer pan for divider sets.
  • Hinged doors with self-closing spring hinges, 180° opening; continuous integrated handle strip; central lock (pin-cylinder lock with 2 keys).
  • Vice: forged, hardened, adjustable guides; jaw width 120 mm, clamping depth 82.5 mm, clamping span 146 mm, anvil 75 x 75 mm, overall length 365 mm, base diameter 150 mm. Folding lift: vice folds under the worktop; integrated height adjustment enables vertical position and rotation.


Material and quality
  • Beech solid worktop produced in-house (from tree to worktop) using PEFC-certified raw material from sustainable regional forestry.
  • Surface protection with lacquered linseed oil (environmentally friendly).


Technical specifications
  • Extension type: partial extension 90%
  • Width: 1250 mm
  • Depth: 700 mm
  • Height: 880 mm
  • Top type: beech solid worktop
  • Top thickness: 40 mm
  • Number of drawers: 1
  • Load capacity (mobile): 450 kg
  • Load capacity (stationary): 1250 kg
  • Mobility: lowerable/retractable chassis
