Digital clamp ammeter 8-024 PLUS
portablefor high-voltage applicationsmeasurement

Digital clamp ammeter - 8-024 PLUS - SENSORLINK - portable / for high-voltage applications / measurement
Digital clamp ammeter - 8-024 PLUS - SENSORLINK - portable / for high-voltage applications / measurement
Add to favorites
Compare this product

Characteristics

Mounting
portable
Domain
measurement, for high-voltage applications, multiple

Description

Subtitle
  • True RMS Ampstik, holds four readings, 5000A, 500kV, Wide Jaw 4" sensor opening

Product Details
  • Contains: Model 8-024 PLUS & 7060WJ canvas carrying case

Range of Operation
  • Voltage: 0 - 500 kV
  • Current: 0.5 - 5000 A

Sensor Opening
  • Standard Opening Width: 4 in, 10.16 cm

Resolution
  • Amps 1 - 99.9 A: 0.1 A
  • Amps 200 - 1999 A: 1 A
  • Amps 2000 - 5000 A: 0.01 kA

Accuracy
  • ± 1% ± 2 counts

Operation
  • Frequency: 60 Hz (57 to 63 Hz) or 50 Hz (47 to 53 Hz) Models Available
  • Controls: One button operation
  • Readings: Four reads

Mechanical
  • Weight Standard Sensor: 2.6 lbs, 1.18 kg
  • Operating Temperature: -22 to 140 degrees F (-30 to +60 degrees C)
  • Display: 3.5 Digit Display
  • Backlight: Automatic ambient light sensor
  • Housing: Fire resistant and waterproof polycarbonate & silicone
  • Hot stick mounting: Universal chuck adapter (Hot stick not included)
  • Battery: 9V Alkaline or Lithium

Characteristics / Technical Specifications
  • Model: 8-024 PLUS
  • Voltage range: 0 - 500 kV
  • Current range: 0.5 - 5000 A
  • Sensor opening: 4 in (10.16 cm)
  • Resolution: 0.1 A (1-99.9 A), 1 A (200-1999 A), 0.01 kA (2000-5000 A)
  • Accuracy: ± 1% ± 2 counts
  • Frequency: 60 Hz (57-63 Hz) or 50 Hz (47-53 Hz)
  • Weight: 2.6 lbs (1.18 kg)
  • Operating temperature: -22 to 140°F (-30 to +60°C)
  • Display: 3.5 digit
  • Backlight: Automatic ambient light sensor
  • Housing: Fire resistant and waterproof polycarbonate & silicone
  • Battery: 9V Alkaline or Lithium
