CNC punching machine SA 121-cn

hydraulicservo-drivenfor PVC profiles

Overview
The SA 121-cn is a CNC traveling-head hydraulic die-cutting press designed for cutting flexible and semi-rigid materials in sheet or roll form. The die is mounted under the traveling head to ensure stability and repeatable precision during cutting.

Video
Demonstrates the smooth, precise travel of the moving head — the central element of the cutting system.

Key features
The cardboard cutting belt offers a cost-effective, easy-to-replace solution that reduces maintenance. Nesting software optimizes cut placement to minimize material waste. An automatic tool magazine is available for quick tool changes and to integrate multiple cutting shapes within a single production cycle. The SA 121-cn can cut multiple material layers simultaneously to increase throughput.

Advantages

• Cardboard cutting belt: economical and easily replaceable
• Servo-pump integrated into the traveling head: low oil requirement, energy-efficient, reduced noise
• Operator protection by a safety light curtain
• Rigid welded frame
• User-friendly HMI with intuitive controls
• HMI position configurable left or right; create and store production programs
• Multi-language interface
• Capable of cutting simple or complex shapes with minimal waste
• High cutting accuracy and constant parallelism
• Minimal cleaning and low maintenance needs
• Easy access for maintenance
• Hydraulic power unit and electrical panel integrated into the machine
• Tool loading possible from left or right

Multiple Applications

• Rubber
• Cardboard
• Leather
• Felt
• Insulation materials
• Gaskets
• Cork
• Carpet
• Foam
• Paper
• Plastics
• PVC
• Flooring materials
• Synthetic materials
• Textiles

Sectors

• Aeronautics
• Furniture
• Automotive
• Composites
• General industry
• Bedding
• Leather goods
• Medical
• Packaging
• Thermoformed parts
• Point of sale
• Saddlery

Why choose Suteau-Anver?
With nearly 80 years of experience, Suteau-Anver supplies machines adapted to manufacturers' needs and offers industry-specific know-how.

Spare parts
Suteau-Anver maintains a centralized spare-parts warehouse with over 20,000 references covering its own machines and partner equipment for distribution in France.

After-sales service (SAV)
A knowledgeable hotline provides first-level diagnostics and, where possible with user assistance, remote troubleshooting.

Technical features
Power supply: Three-phase 400 V + Neutral + Earth
Electrical power: 16 kW
Control circuit voltage: 24 V
Pneumatic supply: 6 bar
Cutting speed: 50–200 mm/s
Adjustable stroke: 5–210 mm
Cutting power: 50 tons
Maximum daylight without cutting block: 210 mm
Maximum tool dimensions: 850 × 850 mm
Useful width: 1900 mm
Maximum material height: 110 mm
Fast descent/ascent speed: 200 mm/s
Maximum rate: 18–50 cuts/min (depends on shape/size and material height)

Options

• Remote maintenance
• Automatic tool change
• Alternative cutting powers
• Other tool dimensions available
• Other material widths available
• Alternative conveyor belts
• Systems for collecting cut parts: robot, unstacker, gripper
