Rotary cutting machine

for rubberfor foamfor composite materials

Short description
The SUTEAU-ANVER High-Speed Rotary Die-Cutter is a rotating die-cutting machine designed for high-throughput cutting of flexible materials. It performs both cut-through and kiss-cut operations and is developed as a compact, serviceable unit for industrial production.

Applications - Materials

• Foam
• Rubber
• Paper
• Cardboard
• Composites

Functional description
The rotating die is engineered in collaboration with specialist die-makers and validated on customer-supplied roll materials. The machine architecture enables rapid tool change, precise cutting position adjustment and efficient evacuation/collection of cut parts to maintain high production rates.

Key features

• Rotary cutting tool suitable for precise contour and repeatable die cuts
• Fast tool changing system to reduce downtime
• Cutting position adjustment by manual micrometric screw or pressure-based system
• Adjustable operating speed from 0 to 500 rpm
• Asynchronous motor with speed variator and operator console
• Safety guards in altuglass and sliding door for operator protection
• Automatic pieces collection or evacuation on output plate
• Customizable die designs to match imprint shapes and production needs

Options

• Part counter/servo for imprint counting
• Material unwinders and rewinders
• Feeding systems (manual or automated)
• Integration into larger production lines

Available versions
Multiple configurations and line integration options are available to suit production requirements; specific versions can be supplied on request.

Technical features

• Brand: SUTEAU-ANVER
• Model family: High-Speed Rotary Die-Cutter
• Rotating die maximum width: 1000 mm (with input guiding)
• Speed range: 0–500 rpm (adjustable)
• Motor type: Asynchronous motor
• Electric power: 5 kW
• Machine weight: 600 kg
• Fast tool changing system for reduced downtime
• Cutting position adjustment: manual micrometric screw or pressure-based
• Control cabinet: speed variator, operator console and safety guards
• Safety: altuglass guards and sliding door
• Options: part counter, unwinders/rewinders, feeding systems, full line integration
