Laser trackball X13

panel-mountruggedprecision

Product Description
The X13 trackball from Cursor Controls is a compact, solid‑state laser‑tracking trackball engineered for back‑of‑panel mounting in OEM keyboards and consoles. With no moving sensing parts other than the ball, the X13 provides precise cursor control across a wide speed range and reliable operation in harsh environments, making it suitable for industrial, medical and marine control interfaces.

Features

• Solid state sensing technology – laser tracking engine
• Sealing up to IP68
• Outputs: USB & PS/2 (auto-select) & SUN Systems or TTL Quadrature
• Smooth operation in rugged environments
• Various top plate configurations
• Custom connector options
• External Switch Connections (USB/PS2 only)

Typical Applications

• Medical systems
• Marine systems
• Custom keyboard applications
• Industrial consoles
• OEM custom solutions available

Product Configuration (ordering code overview)
Ordering code base: X13 - variants shown below

Sealing Rating

• IP68 (default)

Output Protocol

• Combined Interface - PS/2 & USB
• Quadrature

Integrated Switches

• No switches (default)

Mounting Style

• Mount to back of panel (default)

Top & Body Style

• X13 Damper Ring
• X13 Rubber Ball Seal

Ball Colour

• Metallic Grey
• Black

Suffix

• K - Optical Tracking Engine (default)

Technical Specifications

• Model: X13
• Brand: Cursor Controls
• Tracking technology: Laser tracking engine (solid state sensing)
• Sealing: Up to IP68
• Outputs supported: USB & PS/2 (auto-select); SUN Systems; TTL Quadrature
• Mounting: Designed for back-of-panel mounting (OEM keyboards and consoles)
• Operation: Smooth operation in rugged environments
• Top/Body options: X13 Damper Ring; X13 Rubber Ball Seal
• Integrated switches: Option for no switches (other switch options may be available)
• Ball colours available: Metallic Grey, Black
• Suffix/engine option: K = Optical Tracking Engine
• Customisation: Various top plate configurations and custom connector options available
