Ultrasonic transit-time flow transducer BBFM-Q160K

gas

Product overview
The BBFM-Q160K is an ultrasonic gas flow measurement transducer specified for industrial gas flow meters, gas meters, gas velocity measurement and transit-time gas measurement modules. Its center frequency is 160 kHz ±5%, with a reference range of 0.15 to 2 m. The half-power beam angle is 9.8° ±10% at -3 dB.

Performance and interface specifications
Parameter : Specification
Model : BBFM-Q160K
Center frequency : 160 kHz ±5%
Recommended range : 0.15 to 2 m
Minimum impedance : 350 Ω ±20%
Capacitance : 900 pF ±20% at 1 kHz
Operating voltage : Peak voltage <450 Vpp
Operating temperature : -40 to +80°C
Pressure rating : ≤16 kgf or 1.6 MPa
Half-power beam angle : 9.8° ±10% at -3 dB
Housing material : Titanium alloy
Mounting : Refer to the product dimensional drawing
Protection rating : IP68
Weight : 10.5 g ±5% with 22 cm cable

Metering functions stated in the source

• Industrial gas flow meters
• Gas meters
• Gas velocity measurement
• Transit-time gas measurement modules

Matching the acoustic path and electronics
The acoustic path should be selected within the 0.15 to 2 m reference range while considering the 9.8° half-power beam angle, the operating gas and the available mounting geometry. The electronic interface should be matched to the 350 Ω ±20% minimum impedance and the 900 pF ±20% capacitance measured at 1 kHz. Peak voltage must be kept below 450 Vpp.

Environmental and configuration checks
Confirm operation within -40 to +80°C and at no more than 16 kgf or 1.6 MPa. The transducer is rated IP68. The stated 10.5 g ±5% weight applies to the version with a 22 cm cable, while exact mounting dimensions should be taken from the product drawing.

Caractéristiques / spécifications techniques

• Model: BBFM-Q160K
• Center frequency: 160 kHz ±5%
• Recommended (reference) range: 0.15 to 2 m
• Half-power beam angle: 9.8° ±10% at -3 dB
• Minimum impedance: 350 Ω ±20%
• Capacitance: 900 pF ±20% at 1 kHz
• Operating voltage: Peak voltage <450 Vpp
• Operating temperature: -40 to +80°C
• Pressure rating: ≤16 kgf or 1.6 MPa
• Housing material: Titanium alloy
• Protection rating: IP68
• Weight: 10.5 g ±5% (with 22 cm cable)
