Pressure calibrator CAL-150 series
for pressure sensorsportableautomatic

Pressure calibrator - CAL-150 series - Instrumentys - for pressure sensors / portable / automatic
Pressure calibrator - CAL-150 series - Instrumentys - for pressure sensors / portable / automatic
Add to favorites
Compare this product
Go to the Instrumentys website for more information

Characteristics

Physical quantity
pressure
Applications
for pressure sensors
Options
portable, precision, automatic, low-pressure
Pressure

Min.: 0 Pa
(0 psi)

Max.: 1,000 Pa
(0.15 psi)

Voltage

Min.: 0 V

Max.: 2 V

Description

Presentation
Portable pressure generator CAL-150-1000Pa, precision automatic pressure calibrator with integrated pressure generator.

Main features
  • Integrated portable pressure generator
  • Automatic low-pressure calibrator
  • Metal housing
  • Reset button

Technical information and performance
  • Pressure range: 0 - 1000 Pa
  • Pressure output signal: 0…2 V (standard)
  • Linearity: 0.20% of full scale for > 100 Pa; 0.20 Pa FS for < 100 Pa
  • Repeatability: 0.02%
  • External power supply: 230 VAC → 24 VAC converter
  • Protection rating: IP44
  • Tubing connection: 6 mm diameter
  • Calibration certificate: UKAS

Characteristics / technical specifications
  • Type: Automatic low-pressure generator / calibrator
  • Model series: CAL-150
  • Measurement range: 0 to 1000 Pa
  • Electrical output: 0…2 V
  • Accuracy / linearity: 0.20% FS (>100 Pa); 0.20 Pa FS (<100 Pa)
  • Repeatability: 0.02%
  • Power supply: 230 VAC → 24 VAC converter (external)
  • Housing: Metal
  • Protection rating: IP44
  • Connection: tube Ø 6 mm
  • Additional functions: reset button
  • Delivered with: UKAS calibration certificate
