Thermocouple thermometer MH 3211

digitalRS-232portable

Description
Portable precision thermocouple thermometer compatible with various types of thermocouple probes. High measurement accuracy is achieved through high-performance sensors and digital linearization of the characteristic curve. Robust, ergonomic design adapted for field use; membrane keys provide a high level of protection against dust and moisture. Automatic probe recognition via standard DIN connector. Serial interface for data transfer and retrieval of stored values. Acquisition and analysis software available for recording, viewing and exporting data.

Key points

• Wide measurement range covering industrial applications
• Fine resolution for precise readings
• High accuracy with two uncertainty formulas depending on the range
• Compatible with many thermocouple types
• Serial interface for communication and data logging
• Very fast response time
• Automatic probe recognition (plug-and-play)

Usage and options
Instrument intended for industrial and laboratory temperature measurements. Compatible probes are available for a wide range of applications. Software enables recording, extended display and analysis of measurement sequences; data can be exported for further processing (e.g. spreadsheet). Calibration traceable to international standards or COFRAC calibration available as an option (certificate and number of points to specify when ordering).

Characteristics / technical specifications

• Measurement range: -220 to 1750 °C
• Resolution: 0.1 °C / 1 °C
• Accuracy: ±(0.5 °C + 0.2 % of reading) and ±(0.8 °C + 0.4 % of reading) (depending on range)
• Input: Thermocouples K / J / S / T / N / E / B
• Interface: Serial interface for data transfer and PC communication
• Memory: Values recordable and transferable via software
• Compatible software: Recording and analysis software (examples listed in product documentation)
• Housing: Ergonomic design, membrane keys protected against dust and moisture
• Plug-and-play: Automatic probe recognition via DIN connector
• Response time: Very fast
• Calibration: Traceable calibration to international standards or COFRAC calibration available as option
