Pressure calibrator CAL-150
for pressure sensorsportableautomatic

Pressure calibrator - CAL-150 - Instrumentys - for pressure sensors / portable / automatic
Pressure calibrator - CAL-150 - Instrumentys - for pressure sensors / portable / automatic
Add to favorites
Compare this product
Go to the Instrumentys website for more information

Characteristics

Physical quantity
pressure
Applications
for pressure sensors
Options
portable, precision, automatic, low-pressure
Pressure

Min.: 0 Pa
(0 psi)

Max.: 100 Pa
(0.01 psi)

Voltage

Min.: 0 V

Max.: 2 V

Description

Summary
  • Portable automatic low-pressure generator with built-in pump.
  • Precision pressure calibrator designed for calibration and verification of instruments measuring very low pressures.
  • Supplied with UKAS calibration certificate.

Description
  • Integrated pressure generator
  • Pressure range: 0 - 100 Pa
  • Pressure output signal: 0…2 V (standard)
  • Linearity: 0.2% of full scale
  • Repeatability: 0.02%
  • External power supply: converter 230 VAC → 24 VAC
  • Zero reset button
  • Metal enclosure
  • Protection rating: IP44
  • Tubing connection: 6 mm diameter

Remarks
  • Product presented as an automatic, portable pressure calibrator (built-in pump).
  • Calibration certificate supplied (UKAS).

Technical specifications
  • Model: CAL-150 (see commercial designation)
  • Range: 0 to 100 Pa
  • Accuracy / linearity: 0.2% of full scale
  • Repeatability: 0.02%
  • Electrical output: 0…2 V
  • Power supply: 230 VAC to 24 VAC converter (external)
  • Enclosure: metal
  • Protection rating: IP44
  • Connection: 6 mm tubing
  • Supplied accessories/documents: UKAS calibration certificate
Go to the Instrumentys website for more information
