Liquids dosing dispenser ALIVA 403.6

with piston pumpmanualautomatic

Overview
The Aliva 403.6 is an additive dosing unit designed for precise metering of liquid admixtures used in spraying and shotcrete applications. It is supplied with an Inox fitting with manometer and a suction hose with lance as standard. An optional backflow preventer is available for drinking-water protection.

Variants
Aliva 403.6 Air
Driven by compressed air. Required supply: 7 bar and 3 Nm³/min. Delivery ranges depend on pump size: DL10: 40–240 litres/h; DL18: 150–700 litres/h. Flow is regulated by the air feed; a display shows the exact pumped volume.

Aliva 403.6 Manual
Electric drive with flow control via a potentiometer on the frequency converter. Delivery range: 30–700 litres/h.

Aliva 403.6 Synchro
Output is automatically synchronized to a rotor machine or concrete pump. After programming cement content and volume per revolution or stroke, the control converts the required delivery rate. Dosing starts and stops in sync with the feeding machine. Delivery range: 30–700 litres/h.

Key specifications

• Aliva 403.6 Air pumping output: 40–700 litres/h
• Aliva 403.6 Manual pumping output: 30–700 litres/h
• Aliva 403.6 Synchro pumping output: 30–700 litres/h
• Designed for additive dosing in dry and wet spraying
• Compatible with any pump or rotor machine

Features

• Inox fitting with manometer and push switch (standard)
• Air or electric drive options
• Manual or synchronized flow adjustment
• Includes suction hose with lance

Benefits

• Accurate factory-set dosing
• Stepless output adjustment across variants
• Can be integrated with piston pumps, rotor machines or concrete pumps
• Dry-run resistant design

Technical specifications

• Model: Aliva 403.6 (Air, Manual, Synchro)
• Drive options: compressed air (Air) or electric (Manual / Synchro)
• Compressed air requirement (Air): 7 bar, 3 Nm³/min
• Pumping output ranges: DL10 (40–240 litres/h), DL18 (150–700 litres/h); Manual and Synchro: 30–700 litres/h
• Flow control methods: air regulation (Air); potentiometer on frequency converter (Manual); automatic synchronization with rotor machine or concrete pump (Synchro)
• Standard equipment: Inox fitting with manometer and push switch; suction hose with lance
• Optional: backflow preventer for drinking-water protection
• Applications: additive dosing for dry and wet spraying; compatible with pumps and rotor machines; suitable for shotcrete and spraying operations
