Ball valve ITEM 101
leverfor waterbrass

ball valve
ball valve
ball valve
Add to favorites
Compare this product

Characteristics

Type
ball
Operation
lever
Media
for water
Body
brass
Other characteristics
2-way
Temperature

Max.: 150 °C (302 °F)

Min.: -20 °C (-4 °F)

Pressure

Max.: 64 bar (928.2 psi)

Min.: 25 bar (362.6 psi)

DN

Max.: 80 mm (3.15 in)

Min.: 10 mm (0.394 in)

Description

GENERAL FEATURES: • The valve is suitable for medium pressures on condition that non aggressive fluids are used. • Working temperature: from -20°C to +150°C for fluids. • Working pressure: see diagram. • Fluid range: air, water, oil, gas, petroliferous and petrochemical products, vacuum. • Threaded ends as per EN 10226-1 Rp (Ex ISO 7/1) specifications. • Head of the valve as per ISO 5211 specifications • Available version with self-scraping ball profile seal, suitable to be used with dirty fluids or with solid particles inside ON REQUEST: • NPT threaded ends • For other applications, please contact our technical department. CERTIFICATIONS: • According to 2014/68/EU “PED” • ATEX version in conformity with directive 2014/34/EU on request
