Single-axis tilt sensor NTS3

digitalRS-485RS-232

Product introduction
The NTS3 series tilt sensor is a compact digital-output MEMS tilt sensor designed for static and slowly changing dynamic angle measurement in industrial environments. It integrates a dual-channel gravity measurement unit to convert gravitational acceleration into roll and pitch angles relative to the horizontal plane. Output interfaces are selectable: RS232, RS485 or TTL. An onboard MCU performs secondary linearity correction to improve output accuracy compared with basic analog sensors. The sensor uses a non-contact measurement principle, provides real-time attitude output, is easy to install and does not require repositioning opposing surfaces.

Key features

• Single- or dual-axis tilt measurement (roll and pitch)
• Selectable measuring ranges: ±10°, ±30°, ±60°, ±90°
• High resolution: 0.02°
• Standard DC 5V power supply
• Protection rating IP67 for harsh environments

Performance Parameters (table)
Measurement range: ±10° / ±30° / ±60° / ±90°
Measuring axis: X, Y
Resolution: 0.02°
Measurement accuracy (@25°C): 0.1°
Zero-point temperature coefficient (-40–85°C): ±0.02 °/°C
Sensitivity temperature coefficient (-40–85°C): ≤150 ppm/°C
Power-on startup time: 0.5 s
Response frequency: 20 Hz
Output rate: 5 Hz / 15 Hz / 35 Hz / 50 Hz (adjustable)
Output signal: RS232 / RS485 / TTL (customizable)
Electromagnetic compatibility: According to EN61000 and GBT17626
MTBF: ≥98,000 hours
Insulation resistance: ≥100 MΩ
Impact resistance: 100 g @ 11 ms, triaxial (half-sine)
Vibration resistance: 10 grms, 10–1000 Hz
Waterproof rating: IP67
Cable: standard 2 m, wear-resistant, oil-resistant, low/high-temperature shielded cable (4×0.3 mm²)
Weight: ≤105 g

Technical specifications

• Model: NTS3
• Output interfaces: RS232 / RS485 / TTL
• Measuring axes: X, Y
• Available measuring ranges: ±10°, ±30°, ±60°, ±90°
• Resolution: 0.02°
• Accuracy (@25°C): 0.1°
• Protection rating: IP67
• Power supply: DC 5V (standard)
• Output rate: 5 / 15 / 35 / 50 Hz (adjustable)
• Startup time: 0.5 s
• Weight: ≤105 g
