Machine monitoring vibration sensor VTS6D

for machine condition monitoringfor harsh conditionsfor preventive maintenance

Product introduction
The VTS is a high-precision industrial-grade sensor developed by RUICOM Technology for vibration and tilt-angle measurement. Each unit undergoes full-temperature-range calibration compensation and stability testing before shipment to ensure reliable measurement performance across varied environments. An integrated Fast Fourier Transform (FFT) algorithm detects mechanical vibrations in the 0.5–20 Hz band, enabling calculation of peak velocity and maximum displacement amplitude via frequency analysis. The device supports multiple industrial interfaces (RS485 / RS422 / RS232) and the MODBUS protocol. It includes professional data-analysis software for real-time monitoring, recording and in-depth analysis. The non-contact installation design allows secure screw mounting to the target surface and automatic horizontal tilt-angle calculation to speed deployment. With strong electromagnetic immunity and mechanical shock resistance, the VTS series is suitable for demanding mobile platforms and complex environments such as satellite communication vehicles, special command vehicles and radar-antenna vehicles.

Key features

• High-precision inclinometer and vibration sensor
• Built-in FFT algorithm for vibration analysis (0.5–20 Hz)
• Dual-axis inclination measurement (XY)
• High resolution and accuracy (resolution 0.0005°, accuracy 0.001°)
• Optional horizontal or vertical orientation
• Multiple industrial interfaces: RS485 / RS232 / RS422; supports MODBUS
• Robust design with strong EMC performance and mechanical shock resistance

Applications

• Attitude measurement on high-end mobile platforms (satellite communication vehicles, special command vehicles, radar antenna vehicles)
• Industrial vibration monitoring and diagnosis
• Precision tilt/level monitoring in harsh environments

Technical specifications

• Model: VTS6D
• Measure range: ±10°
• Measure axis: XY (dual axis)
• Resolution: 0.0005°
• Measure accuracy: 0.001°
• Zero temperature coefficient: 0.0003°/°C
• Sensitivity temperature coefficient: ≤50 ppm/°C
• Power on time: <0.5 s
• Response frequency: 20 Hz
• Output rate: configurable 5 Hz / 10 Hz / 25 Hz / 35 Hz / 50 Hz / 100 Hz
• Output signal / interfaces: RS485 / RS232 / RS422 (optional)
• Communication protocol: supports industrial-standard MODBUS
• EMC: according to EN61000 and GBT17626
• MTBF: ≥98,000 hours
• Insulation resistance: ≥100 MΩ
• Shockproof: 100 g @ 11 ms (3 axial directions, half sinusoid)
• Anti-vibration: 10 grms / 10 ~ 1000 Hz
• Protection grade: IP67
• Cables: standard 1 meter long wear-resistant, wide-temperature, shielded cable with aviation connector; weight ≤150 g
• Weight: ≤425 g (excluding cable)
• Vibration detection capability: detects mechanical vibrations in 0.5–20 Hz and computes peak velocity and maximum displacement amplitude via frequency analysis
