Single-axis inclinometer NTS6

current outputanalog4-20 mA

Product overview
The NTS6 series tilt sensor from RUICOM is a compact MEMS single-axis inclinometer providing a linear 4–20 mA current output after internal double-linearity correction. Designed for installations with limited space and cost constraints, it supports long-distance signal transmission up to 2000 m and offers robust immunity to electromagnetic interference, shock and vibration for stable operation in harsh industrial environments. The sensor uses a non-contact measurement principle to deliver real-time current-proportional angle output and allows straightforward mounting without complex calibration of moving surfaces. Typical applications include industrial automation, platform attitude monitoring and machine alignment. It is optimized for static and slowly varying dynamic angle measurements.

Key features

• Analog output: 4–20 mA
• Typical accuracy: 0.1° (range dependent)
• Selectable measuring ranges: ±30°, ±60°, ±90°, ±180°, 0–360°
• Power supply: DC 9–36 V
• Operating temperature: -40 to +85 °C
• Long-distance transmission up to 2000 m
• Non-contact measurement for real-time angle output
• Good EMC, shock and vibration resistance
• Ingress protection: IP67; easy installation

Performance parameters (table)
Measurement range: ±30°, ±60°, ±90°, ±180°, 0–360°
Measurement axis: ±30/±60/±90 → X/Y; ±180/0–360 → X
Zero output (0°): 12 mA (all ranges)
Resolution: ±30 → 0.02°; ±60 → 0.03°; ±90 → 0.05°; ±180 → 0.08°; 0–360 → 0.08°
Measurement accuracy (@25 °C): ±30 → 0.1°; ±60 → 0.1°; ±90 → 0.15°; ±180 → 0.2°; 0–360 → 0.2°
Long-term stability: <0.5° (all ranges)
Zero temperature coefficient (-40–85 °C): ±0.02 °/°C (all ranges)
Sensitivity temperature coefficient (-40–85 °C): ≤150 ppm/°C (all ranges)
Power-on startup time: 0.5 s
Response frequency: 20 Hz
Electromagnetic compatibility: compliant with EN61000 and GBT17626
Insulation resistance: ≥100 MΩ
Shock resistance: 100 g @ 11 ms, triaxial (half-sine)
Vibration resistance: 10 grms, 10–1000 Hz
Ingress protection: IP67
Cable: standard 2 m shielded cable; cable weight ≤123 g
Weight: ≤112 g

Technical specifications

• Model: NTS6
• Output signal: 4–20 mA
• Measuring ranges: ±30°, ±60°, ±90°, ±180°, 0–360° (selectable)
• Typical accuracy: 0.1° (range dependent)
• Resolution: down to 0.02° (range dependent)
• Power supply: DC 9–36 V
• Operating temperature: -40 to +85 °C
• Transmission distance: up to 2000 m
• EMC: compliant with EN61000 and GBT17626
• Shock & vibration: 100 g @ 11 ms / 10 grms 10–1000 Hz
• Ingress protection: IP67
• Cable: 2 m shielded cable standard
• Startup time: 0.5 s; Response frequency: 20 Hz
• Long-term stability: <0.5°
