Single-axis tilt sensor LTS6

analogvoltage output0-5 V

Product Introduction
The LTS6 series voltage-output tilt sensor is a compact, low-power angle measurement device developed by Ruiguan Technology. Based on an anti-interference platform and a capacitive MEMS sensing core, it delivers wide-temperature operation, strong vibration and shock tolerance, and stable long-term performance with a designed service life up to 10 years. The sensor uses a non-contact capacitive MEMS principle to detect gravity components and compute tilt angle. Installation is flexible and can be done directly on the monitored surface without additional mechanical shafts, supporting multiple mounting methods for attitude monitoring in construction machinery, agricultural equipment and other industrial applications.

Key features

• 0–5V analog voltage output
• Wide input voltage range: 9–36V
• High vibration and shock tolerance
• Designed service life up to 10 years (99,999 hours no-failure metric)
• Non-contact capacitive MEMS sensing for stable measurement

Performance parameters

• Model: LTS6
• Output voltage: 0–5V
• Resolution: 0.1°
• Measurement accuracy (@25°C): ±0.2°
• Response time: 0.05 s
• Temperature drift (-40°C to +85°C): ±0.5°
• Input voltage range: 9–36V
• Output load: >500 Ω
• Working life: 99,999 hours (no-failure metric)
• Insulation resistance: >100 MΩ
• Vibration resistance: 10 grms (10–1000 Hz)
• Impact resistance: 100 g @11 ms, triaxial (half-sine)
• Size: L64.5 × W50 × H18.5 mm
• Weight: ≤100 g

Product Dimensions
Reference drawing available: overall size L64.5 × W50 × H18.5 mm. See performance parameters for weight and mechanical footprint.

Technical specifications

• Model / Series: LTS6
• Output voltage: 0–5V
• Resolution: 0.1°
• Measurement accuracy (@25°C): ±0.2°
• Response time: 0.05 s
• Temperature drift (-40°C to +85°C): ±0.5°
• Input voltage range: 9–36V
• Output load: >500 Ω
• Working life: 99,999 hours (no-failure metric)
• Insulation resistance: >100 MΩ
• Vibration resistance: 10 grms (10–1000 Hz)
• Impact resistance: 100 g @11 ms, triaxial (half-sine)
• Size: L64.5 × W50 × H18.5 mm
• Weight: ≤100 g
• Measurement principle: non-contact capacitive MEMS sensing
