Air blower 8 1603 0300

centrifugalfor machinesfor the steel industry

Product description
Mobile pneumatic axial fan with a nominal diameter of 300 mm designed for ventilation and exhaust tasks in industrial environments. Earthing required.

Main attributes

• Energy source: Pneumatic
• Operating pressure: 5 bar
• Nominal diameter: 300 mm

Technical data
ORDER NO.: 8 1603 0300
Energy source: Pneumatic
Operating pressure: 5 bar
Nominal diameter: 300 mm
Volume flow (unrestricted): 0.78 m³/s
Air consumption: 0.58 m³/min
Length: 350.00 mm
Quality of air: oil free
Noise level LpA: 85.0 dB(A)
Weight: 14.0 kg
Fields of application / branch: Energy and pipeline construction; Metal industry and steel construction; Plant and mechanical construction

Accessories

• Protective grill — Order No. 8 1601 2070
• Flange according to DIN 21 603 — Order No. 9 3001 0010
• Connecting piece, antistatic — Order No. 9 3709 0260
• Quick collar, antistatic — Order No. 9 3709 0300
• Air duct, antistatic, 5 m — Order No. 9 3709 0220
• Adapter — Order No. 9 3703 0280; Nominal dia. 300 mm; Reducing to dia. 80 mm
• Adapter — Order No. 9 3703 0290; Nominal dia. 300 mm; Reducing to dia. 100 mm
• Adapter — Order No. 9 3703 0300; Nominal dia. 300 mm; Reducing to dia. 150 mm
• Adapter — Order No. 9 3703 0050; Nominal dia. 300 mm; Reducing to dia. 200 mm
• Earthing cable — Order No. 9 3707 0020

Characteristics / specifications

• Order number: 8 1603 0300
• Energy source: Pneumatic
• Operating pressure: 5 bar
• Nominal diameter: 300 mm
• Volume flow (unrestricted): 0.78 m³/s
• Air consumption: 0.58 m³/min
• Length: 350.00 mm
• Quality of air: oil free
• Noise level LpA: 85.0 dB(A)
• Weight: 14.0 kg
• Fields of application: Energy and pipeline construction; Metal industry and steel construction; Plant and mechanical construction
• Earthing required
