管理型イーサネットスイッチ 9015-8GT-I

8 ポートDINレールDIP

Product OverviewWoodpecker 9015-8GT-I is a high-performance 8-port 10/100/1000 RJ45 managed industrial switch designed for communication between controllers and devices in automation environments. It is used with peripheral devices such as multi-axis robots, PLCs, HMIs, and legacy devices. All ports provide auto-negotiation and Modbus TCP, making it easy to aggregate devices in industrial Ethernet applications. The switch optimizes traffic using storm, flow control, and QoS, prioritizes industrial data packets, prevents data loss during communication, and ensures stable transmission. It also features a topology map for network visualization and complies with cybersecurity standards to protect network vulnerabilities.This switch is built with industrial-grade components and enclosed in a high thermal conductivity IP30 aluminum case, protecting the device from tools and hazards. It is designed to withstand vibration, shock, free fall, interference, and temperatures from -40°C to 75°C (-40°F to 167°F), making it suitable for harsh industrial applications. For reliability, redundant power and alarm relay contacts on the terminal block ensure non-stop operation and provide warnings in case of power failure.Features8 x 10/100/1000 RJ45 ports (supports industrial devices such as PLCs, HMIs, printers for automation systems)Topology map for network monitoringStorm control, flow control, and QoS to optimize network performanceOperating temperature range: -40°C~75°C (-40°F~167°F), IP30 metal housingFunctionsResistant to industrial environments: Tested and certified for safe use under harsh conditions. Designed to withstand electromagnetic interference, electrostatic discharge, power surges, overvoltage, overcurrent, and reverse polarity. Operating temperature range: -40°C to 75°C.Shock (IEC 60068-2-27) | Free fall (IEC 60068-2-32) | Vibration (IEC 60068-2-6)Secure remote management control: Provides secure features such as SSH, HTTPs, SNMPv3, 802.1X, TACACS+ to allow users to operate the switch in a protected state, defending the network from malicious attacks.Network monitoring tools: Tools such as cable test, multicast address, MAC flapping help identify issues that may affect industrial processes.Redundant power supply: Designed to connect to two power supplies simultaneously, with alarms set via standard industrial terminal blocks. If one power supply fails, the switch draws power from the alternative source and triggers an alarm to notify technicians.SpecificationsStandards: IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3ab (1000BASE-T), IEEE 802.3 (Nway Auto-negotiation), IEEE 802.3x (Flow Control), IEEE 802.3ad (Link Aggregation), IEEE 802.3az (Energy Efficient Ethernet), IEEE 802.1AB (LLDP), IEEE 802.1ad (QinQ), IEEE 802.1D (STP), IEEE 802.1w (RSTP), IEEE 802.1p (Class of Service), IEEE 802.1Q (VLAN Tagging), IEEE 802.1X (Port Authentication)Interface: 8x10/100/1000Base-T ports, DIP Switch (Primary/Redundant Power Voltage Drop Alarm setting), LED Panel (PWR, RPS, ALM, SFP, 1000, LNK/ACT)Power: Input Voltage: Primary inputs: 24~48V DC, Redundant inputs: 24~48V DC; Connection: Terminal Block; Power Consumption: 9015-8GT-I: Max. 10W, 24V DC @ 0.35A; Alarm Relay: One relay output with current carrying capacity of 1A @ 24V DCMechanical and Environment: Housing: Metal (IP30 Protection); Mounting: DIN-Rail; Operating Temperature: -40°C~75°C (-40°F~167°F); Storage Temperature: -40°C~85°C (-40°F~185°F); Operating/Storage Humidity: 5 to 95% RH (non-condensing); Dimension (WxHxD): 50 x119.2 x 99.9mm (1.97 x 4.69 x 3.93in); Weight: 550g (1.2lb)Ordering InformationModelDescriptionWoodpecker 9015-8GT-IManaged 8 x 10/100/1000 RJ45 SwitchKey Technical Specifications8 x 10/100/1000 RJ45 managed portsIndustrial-grade, IP30 aluminum housingOperating temperature: -40°C to 75°CRedundant power supply supportComprehensive network management and security featuresDIN-rail mountingDimensions: 50 x 119.2 x 99.9 mmWeight: 550g
