Triangular prism #83-3 series

fused silica

TECHSPEC® High Power Laser Line Fused Silica Right Angle Prisms provide high damage thresholds ranging from 2 - 5J/cm2 allowing for easy integration into most Nd:YAG laser systems. They feature low arcsecond angle tolerance and are made from precision UV fused silica, making them ideal for laser based applications requiring precise alignment. 355nm, 532nm and 1064nm Options Available High Damage Threshold Ray Deviation of 90° Additional Right Angle Prisms Available Common Specifications Dimensional Tolerance (mm): +0.00/-0.10 Bevel: Protective as needed Angle Tolerance (arcsec): ±40 Substrate: Fused Silica (Corning 7980) Surface Quality: 20-10 Pyramid Tolerance (arcmin): ±1 Image Orientation: Left-Handed Ray Deviation (°): 90 Power (fringes) @ 632.8nm: 1.25 Irregularity (fringes) @ 632.8nm: 0.20
