Mobile pressure test unit DC-360

The DC-360 electric test pump is a portable pressure pump designed for pressure testing of water, gas and oil pipelines, offering a compact construction, stable output pressure and low energy consumption. Supplied with a 2-year warranty and CE certification.

Key features

• Compact construction and easy portability
• Stable output pressure, selectable up to 25 / 40 / 60 bar (2.5 / 4.0 / 6.0 MPa)
• Low energy consumption and simplified maintenance
• Flow rate: 420 L/h; rotational speed: 2800 rpm
• Motor power: 1800 W
• Warranty: 2 years; Certification: CE

Applications

• Pressure testing and leak detection for water pipelines
• Pressure tests for gas pipelines
• Testing of oil/petroleum pipelines and related installations
• Use on construction sites, maintenance of pressurized systems and quality control

Technical specifications

• Models: DC-360, DC-360A, DC-360B
• Pressure options (max): 2.5 MPa (25 bar), 4.0 MPa (40 bar), 6.0 MPa (60 bar)
• Power: 1800 W
• Flow rate: 420 L/h
• Speed: 2800 rpm
• Frequency: 50 Hz
• Gross weight / Net weight: DC-360 = 15.6 / 10.7 kg; DC-360A = 12.4 / 8.4 kg; DC-360B = 12.6 / 8.6 kg
• Dimensions: DC-360 = 40 x 25 x 35 cm; DC-360A / DC-360B = 46 x 27 x 27 cm
• Customization: color, model and logo options available
