Workshop pressure test unit DC series

mobile

The DC Series electric test pressure pump (DC-120 / DC-160) is a portable, industrial-grade pump designed for pressure testing pipelines and pressure vessels in oil, gas and water systems. The unit delivers a stable output pressure with efficient power consumption and is built for easy transport and on-site maintenance.

Key features

• Compact, portable design for site mobility
• Stable and controllable output pressure for accurate tests
• Energy-efficient electric drive
• Simple maintenance and straightforward operation
• 2-year warranty; CE certified

Applications

• Pressure testing of oil, gas and water pipelines
• Pressure vessel and tank testing
• Pipeline commissioning and leak detection
• Use on construction sites, in maintenance workshops, fire stations and utility works

Data sheet

• Model DC-120 — Pressure: 0–12 MPa (0–120 bar); Power: 120 W; Input voltage: 220 V; Output: 24 V; G.W/N.W: 4.5/3.5 kg; Dimensions: 36 × 24.5 × 21 cm
• Model DC-160 — Pressure: 0–16 MPa (0–160 bar); Power: 180 W; Input voltage: 220 V; Output: 24 V; G.W/N.W: 4.8/3.8 kg; Dimensions: 38 × 24.5 × 21 cm

Technical specifications

• Brand: MM-Tech
• Series: DC Series electric test pressure pump (models DC-120, DC-160)
• Designed for portable field testing and workshop inspections
• Stable pressure output suitable for precise pressure and leak tests
• Low power consumption for extended on-site use
• Warranty: 2 years
• Certification: CE
