Manual stacker truck MT1015

hydraulicwalk-behindfor warehouse

Description

• Designed for industrial pallet handling and lifting operations.
• Quick lift system for fast initial raising of the forks.
• Compact design with accurate steel construction.
• Hydraulic pump and cylinder with German seals; built-in top-of-stroke bypass valve.
• Conforms to EN1757-1:2001.
• Note: Materials and specifications are subject to change without notice.

Models / Specifications
i-LIFT NO. | Model No. | Capacity kg(lb.) | Min. Fork Height mm(in.) | Max. Fork Height mm(in.) | Fork Length mm(in.) | Overall Forks Width mm(in.)
1520601 | MT1015 | 1000 (2200) | 90 (3.5) | 1500 (59) | 1150 (45.3) | 540 (21.3)
1520620 | MT1029 | 1000 (2200) | 90 (3.5) | 2850 (112.2) | 1150 (45.3) | 540 (21.3)
1520701 | GT1015 | 1000 (2200) | 65 (2.6) | 1500 (59) | 1150 (45.3) | 540 (21.3)
1520702 | GT1029 | 1000 (2200) | 65 (2.6) | 2850 (112.2) | 1150 (45.3) | 540 (21.3)

Technical features / specifications

• Series: MT/GT.
• Capacity: 1000 kg (2200 lb.) for all listed models.
• Min. fork height: MT models 90 mm (3.5 in); GT models 65 mm (2.6 in).
• Max. fork height: 1500 mm (59 in) for 1015 variants; 2850 mm (112.2 in) for 1029 variants.
• Fork length: 1150 mm (45.3 in) for all listed models.
• Overall forks width: 540 mm (21.3 in) for all listed models.
• Hydraulic pump and cylinder with German seals; built-in top-of-stroke bypass valve.
• Quick lift system technology for faster initial lift.
