Semi-electric stacker truck MSSN series

walk-behindfor liftinghigh-lift

Product Overview

• Heavy-duty design with reinforced mast construction for industrial handling.
• Safety guard on load roller and steering wheel to reduce hazards during operation.
• Increased power output to support sustained heavy-capacity cycles.
• Reliable mast steel imported from Germany for improved durability.
• Professional design optimized for workshop and warehouse use.
• Built-in charger available as an option.

Models and dimensions (table)
i-LIFT NO. | Model No. | Capacity kg(lb.) | Min. Fork Height mm(in.) | Max. Fork Height mm(in.) | Fork Length mm(in.) | Overall Forks Width mm(in.)
1561101 | MSS1016N | 1000 (2200) | 85 (3.3) | 1600 (63) | 1150 (45.3) | 550 (21.7)
1561102 | MSS1023N | 1000 (2200) | 85 (3.3) | 2350 (92.5) | 1150 (45.3) | 550 (21.7)
1561103 | MSS1029N | 1000 (2200) | 85 (3.3) | 2900 (114.2) | 1150 (45.3) | 550 (21.7)
1561104 | MSS1035N | 1000 (2200) | 85 (3.3) | 3500 (137.8) | 1150 (45.3) | 550 (21.7)

Characteristics / Technical specifications

• Series: MSSN SERIES
• Brand: i-LIFT
• Available models: MSS1016N, MSS1023N, MSS1029N, MSS1035N
• Rated capacity (all listed variants): 1000 kg (2200 lb)
• Minimum fork height (all listed variants): 85 mm (3.3 in)
• Maximum fork heights by model: MSS1016N - 1600 mm (63 in); MSS1023N - 2350 mm (92.5 in); MSS1029N - 2900 mm (114.2 in); MSS1035N - 3500 mm (137.8 in)
• Fork length (all listed variants): 1150 mm (45.3 in)
• Overall forks width (all listed variants): 550 mm (21.7 in)
• Options: built-in charger (optional)
• Mast material: higher reliability steel imported from Germany
