Semi-electric stacker truck MSS series

battery-poweredfor warehousefor pallet

Product overview

• Mast construction in high-strength steel imported from Germany.
• Safety guard on load roller and steering wheel.
• Traction battery available for higher power; optional built-in charger.
• Designed for pallet handling and stacking in indoor environments.

Models and Dimensions (table)
i-LIFT NO. | Model No. | Capacity kg(lb.) | Min. Fork Height mm(in.) | Max. Fork Height mm(in.) | Fork Length mm(in.) | Overall Forks Width mm(in.)
1550111 | MSS1016 | 1000 (2200) | 85 (3.3) | 1600 (63) | 1150 (45.3) | 550 (21.7)
1550112 | MSS1025 | 1000 (2200) | 85 (3.3) | 2500 (98.4) | 1150 (45.3) | 550 (21.7)
1550113 | MSS1029 | 1000 (2200) | 85 (3.3) | 2900 (114.2) | 1150 (45.3) | 550 (21.7)
1550114 | MSS1031 | 1000 (2200) | 85 (3.3) | 3100 (122) | 1150 (45.3) | 550 (21.7)
1550115 | MSS1033 | 1000 (2200) | 85 (3.3) | 3300 (129.9) | 1150 (45.3) | 550 (21.7)
1550116 | MSS1516 | 1000 (2200) | 85 (3.3) | 1600 (63) | 1150 (45.3) | 550 (21.7)

Technical specifications

• Rated capacity: 1000 kg (2200 lb) for listed models.
• Minimum fork height: 85 mm (3.3 in).
• Maximum fork height: varies by model (from 1600 mm up to 3300 mm as listed).
• Fork length / overall forks width: 1150 mm (45.3 in) fork length; 550 mm (21.7 in) forks width.
• Traction battery option for higher power; optional built-in charger available.
• Mast steel sourced from Germany.
• Safety guard fitted on load roller and steering wheel.
• Intended for indoor pallet handling and stacking operations.
