Electric stacker truck FS series

Overview

• Available with DC or AC drive technology.
• Curtis electric control system for precise handling.
• Power pack using European technology for reliable performance.
• Drive unit equipped with an electromagnetic brake.
• Meets EN1757-1:2001 and EN1727 standards.

Available models / Technical table
i-LIFT NO | Model No. | Capacity kg(lb.) | Min. Fork Height mm(in.) | Max. Fork Height mm(in.) | Fork Length mm(in.) | Overall Forks Width mm(in.)
1550701 | FS1216 | 1200 (2640) | 90 (3.5) | 1600 (63) | 1150 (45.3) | 540 (21.3)
1550702 | FS1516 | 1500 (3300) | 90 (3.5) | 1600 (63) | 1150 (45.3) | 540 (21.3)
1550703 | FS1224 | 1200 (2640) | 90 (3.5) | 2450 (96.5) | 1150 (45.3) | 540 (21.3)
1550704 | FS1524 | 1500 (3300) | 90 (3.5) | 2450 (96.5) | 1150 (45.3) | 540 (21.3)
1550705 | FS1229 | 1200 (2640) | 90 (3.5) | 2900 (114.2) | 1150 (45.3) | 540 (21.3)
1550706 | FS1529 | 1500 (3300) | 90 (3.5) | 2900 (114.2) | 1150 (45.3) | 540 (21.3)
1550707 | FS1231 | 1200 (2640) | 90 (3.5) | 3100 (122) | 1150 (45.3) | 540 (21.3)
1550708 | FS1531 | 1500 (3300) | 90 (3.5) | 3100 (122) | 1150 (45.3) | 540 (21.3)
1550709 | FS1233 | 1200 (2640) | 90 (3.5) | 3300 (129.9) | 1150 (45.3) | 540 (21.3)
1550710 | FS1533 | 1500 (3300) | 90 (3.5) | 3300 (129.9) | 1150 (45.3) | 540 (21.3)
1550711 | FS1216AC | 1200 (2640) | 90 (3.5) | 1600 (63) | 1150 (45.3) | 540 (21.3)
1550712 | FS1516AC | 1500 (3300) | 90 (3.5) | 1600 (63) | 1150 (45.3) | 540 (21.3)
1550713 | FS1224AC | 1200 (2640) | 90 (3.5) | 2450 (96.5) | 1150 (45.3) | 540 (21.3)
1550714 | FS1524AC | 1500 (3300) | 90 (3.5) | 2450 (96.5) | 1150 (45.3) | 540 (21.3)
1550715 | FS1229AC | 1200 (2640) | 90 (3.5) | 2900 (114.2) | 1150 (45.3) | 540 (21.3)
1550716 | FS1529AC | 1500 (3300) | 90 (3.5) | 2900 (114.2) | 1150 (45.3) | 540 (21.3)
1550717 | FS1231AC | 1200 (2640) | 90 (3.5) | 3100 (122) | 1150 (45.3) | 540 (21.3)
1550718 | FS1531AC | 1500 (3300) | 90 (3.5) | 3100 (122) | 1150 (45.3) | 540 (21.3)
1550719 | FS1233AC | 1200 (2640) | 90 (3.5) | 3300 (129.9) | 1150 (45.3) | 540 (21.3)
1550720 | FS1533AC | 1500 (3300) | 90 (3.5) | 3300 (129.9) | 1150 (45.3) | 540 (21.3)

Technical specifications

• Series name: FS/FSAC series.
• Drive technology: DC or AC options available.
• Control system: Curtis electric control system.
• Power pack: European technology power pack.
• Brake: Drive unit with electromagnetic brake.
• Standards: Conforms to EN1757-1:2001 and EN1727.
• Capacity options: 1200 kg (2640 lb) and 1500 kg (3300 lb).
• Minimum fork height: 90 mm (3.5 in).
• Maximum fork height options: 1600 mm (63 in), 2450 mm (96.5 in), 2900 mm (114.2 in), 3100 mm (122 in), 3300 mm (129.9 in) depending on model.
• Fork length (standard on listed models): 1150 mm (45.3 in).
• Overall forks width (standard on listed models): 540 mm (21.3 in).
• Available model variants include FS1216, FS1516, FS1224, FS1524, FS1229, FS1529, FS1231, FS1531, FS1233, FS1533 and AC versions FS1216AC, FS1516AC, FS1224AC, FS1524AC, FS1229AC, FS1529AC, FS1231AC, FS1531AC, FS1233AC, FS1533AC.
