Manual stacker truck NE4012F

walk-behindfor the pharmaceutical industryfor production

Product Overview

• A range of highly maneuverable, lightweight lifts designed to reduce effort for lifting tasks from ground level to over shoulder height.
• Ideal for narrow aisles and confined spaces. Suitable for pharmaceutical, catering, packing line, food processing, warehouse, office, kitchen, laboratory and retail applications.
• Quick lift pump provides high efficiency.
• Non-marking castors as standard.
• Conforms to EN1757.

Technical table
i-LIFT NO. | Model No. | Capacity kg(lb.) | Min. Fork Height mm(in.) | Max. Fork Height mm(in.) | Load Roller mm(in.) | Steering Wheel mm(in.)
1510701 | NE4012F | 400 (880) | 90 (3.5) | 1210 (47.6) | φ75 (φ3) | φ125 (φ5)

Technical specifications

• Model No.: NE4012F
• i-LIFT No.: 1510701
• Capacity: 400 kg (880 lb)
• Min. fork height: 90 mm (3.5 in)
• Max. fork height: 1210 mm (47.6 in)
• Load roller diameter: φ75 mm (φ3 in)
• Steering wheel diameter: φ125 mm (φ5 in)
• Quick lift pump for high efficiency
• Non-marking castors as standard
• Conforms to EN1757
• Designed for narrow aisles and confined spaces; suitable for pharmaceutical, catering, packing line, food processing, warehouse, office, kitchen, laboratory and retail use
