Piston compressor 1L-1H-1V

airelectrically-poweredstationary

Description
The oil-free single-cylinder tank-mounted piston compressor 1HAB-10-M100X is engineered for durability and long service life, making it suitable for demanding operating conditions. The oil-free piston design supplies clean, contaminant-free compressed air.

Designed to provide durability and long life, our single-cylinder tank-mounted models 1L-1H-1V and 2L-2H are a compact solution within our range of piston compressors and vacuum pumps. These models efficiently deliver compressed air or vacuum across a wide range of pressures and flow rates. The robust design incorporates corrosion-resistant internal components and oil-free operation to ensure reliable performance and pure air.

Applications

• High-pressure, constant applications such as cable pressurization, inflation and high-pressure spraying in general industry, food processing, automotive and manufacturing
• 2V vacuum models for component testing, material handling and food preservation

Key features

• Oil-free and durable: Robust construction providing clean, contaminant-free air
• High-pressure capability: Suitable for demanding, constant pressure requirements
• Tank-mounted: Tank-mounted models available from 2 to 60 gallons

Series / type information

• Series: Piston
• Type: Piston compressors

Characteristics / technical specifications

• Reference: 1HAB-10-M100X
• HP: 0.17
• Amps (60 Hz): 3.5 A
• Weight: 17 lb (8 kg)
• Open flow (60 Hz): 1.3 CFM (37 LPM)
• Voltage (60 Hz): 115 V AC
• Regulatory: cURus
• Max pressure: 100 PSI (6.89 bar)
• Phase: Single-phase
• Country of origin: United States
• Flow at max pressure (60 Hz): 0.4 CFM (11.3 LPM)
• Noise level: 70 dBA
• Dimensions: 11.53 L x 5.63 W x 8.46 H (in) — 292.9 L x 143.0 W x 214.9 H (mm)
• Mounting dimensions: 2.75 L x 4.25 W (in) — 69.9 L x 108.0 W (mm)
• Tank-mounted: Tank-mounted models available (2 to 60 gallons)
• Design: Single-cylinder, oil-free, corrosion-resistant internal components
