Piston compressor 7H-8H

airelectrically-poweredstationary

Overview
Our 4-cylinder tank-mounted compressor (7HDD-10-M750X) is engineered for durability and long service life, suitable for a wide range of industrial applications. The oil-free piston design supplies clean, contaminant-free compressed air. This 1.5 HP model (7HDD-10-M750X) operates at 115 / 208-230 VAC with a maximum continuous pressure of 100 PSI and a free-air delivery of 9 CFM (≈ 255 LPM).

Usage and applications
Models 7H and 8H, 4-cylinder tank-mounted units, are intended for demanding applications and harsh operating conditions. These medium- to compact-size piston compressors deliver compressed air across a broad range of pressures and flows. They incorporate corrosion-resistant internal components and oil-free operation for reliable performance and clean air, suited for tasks such as cable pressurization, inflation, spraying, general industry, food & beverage, automotive and manufacturing.

Key features

• Oil-free and durable: Robust construction delivering clean, contaminant-free air.
• High-pressure capability: Designed for sustained high-pressure operation.
• Tank-mounted: Tank options available from 2 to 60 gallons.

Technical specifications

• Reference: 7HDD-10-M750X
• Series: Piston (7H-8H group)
• Description: Tank-mounted piston compressors, oil-free design
• Power (HP): 1.5 HP
• Amps (60 Hz): 20 / 10
• Free air delivery (60 Hz): 9 CFM (≈ 255 LPM)
• Flow at maximum pressure (60 Hz): 5 CFM (≈ 141.6 LPM)
• Maximum pressure: 100 PSI (≈ 6.89 bar)
• Weight: 70 lb (≈ 32 kg)
• Voltage (60 Hz): 115 / 208-230 VAC
• Sound level: 76 dBA
• Dimensions (in): 21 L x 11.98 W x 8.4 H
• Dimensions (mm): 533.4 L x 304.3 W x 213.4 H
• Mounting dimensions (in): 3 L x 4.88 W
• Mounting dimensions (mm): 76.2 L x 124.0 W
• Regulatory: CSA
• Country of origin: United States
