Hydraulic hose crimping machine FP165automaticPLC-controlled
Add to favorites
Compare this product
Characteristics
- Product handled
- hydraulic hose
- Operational mode
- automatic
- Other characteristics
- PLC-controlled
- Crimping force
5,000 kN
- Crimping capacity
Min.: 4 mm
(0.2 in)Max.: 152.4 mm
Description
Feature description：
● SIMENS Precision Digital Control
● Designed for Mass Production
● Large Opening up +125mm
● CE Approved
Main Specification
- SAMWAY FP165
Max Hydraulic Hose
- 6" Industrial Hose
Crimping Range mm
- 4-202
Master Die Length mm
- 120
Max Opening mm
- +125
otor KW7.5 - 7.5KW by SIEMENS
Crimping Force KN
- 5000
Crimpings Per Hour
- 500
Control - Precision Digital Control
Foot pedal
- Standard
Die Rack
- Included
Quick Change Tool
- Included
Backstop Device
- Optional
Mirror
- Included
Control by Pressure
- Included
Noise Level dBA
- 70
Protection Class
- IP56
L*W*H mm
- 1060*1300*1780
Weight KG
- 2850
