Van-mounted aerial work platform KL26

exteriorcompact

Overview
The KL26 telescopic aerial platform is mounted on a chassis with decking made from bamboo fibers, balsa and other bio-based composites. The main advantage is a more eco-friendly carrier using renewable materials whose production absorbs CO2 rather than emits it: absorption of approximately 2 tons of CO2 (compared with production of 1 ton of aluminium which emits about 21.8 tons of CO2). The composite decking provides higher mechanical resistance than aluminium, offers an increased payload of about +20 kg and features a non-slip bamboo top layer with improved weather resistance.

Key data

• Working height: 10.70 m
• Offset: 6.00 m
• Rotation: 360°
• Capacity: 120 kg (1 operator), no outriggers in standard configuration

Description
The KL26 is a compact, mobile telescopic boom lift valued for its size and manoeuvrability; suitable for environmentally responsible work at height. It is particularly recommended for advertising installers and for maintenance of public lighting and overhead networks.

Standard features

• Engine start/stop from the basket
• Independent emergency electric pump with basket controls
• Proportional controls
• Secure access to the working platform
• Hoses and cables routed inside the boom for maximum protection
• Aluminium boom for optimum stability

Options

• 2-man basket (200 kg) with outriggers
• Bamboo decking
• Signalling devices (triflash, 2 flashing lights, reflective strips)
• 220 V socket in the basket
• Trailer hook
• Reinforced suspensions
• Fully opening insulated basket
• Aluminium toolboxes
• Aluminium side panels
• Side ladder rack
• Tool holders in basket
• Green Pack: platform operable with vehicle engine off

Possible types of vehicles

• RENAULT MASTER L2
• IVECO DAILY 35S
• MERCEDES SPRINTER (empt.3665)
• VOLKSWAGEN CRAFTER (empt.3665)
• FORD TRANSIT (empt.3950)

Technical specifications

• Model: KL26
• Working height: 10.70 m
• Offset (horizontal outreach): 6.00 m
• Rotation: 360°
• Capacity: 120 kg (1 operator)
• No outriggers in standard configuration
• Boom type: telescopic; aluminium boom for stability
• Decking composition: bamboo fibers, balsa and other bio-based composites; top non-slip bamboo layer
• Payload gain compared with aluminium decking: approximately +20 kg
• Environmental benefit: decking production absorbs ~2 tons CO2 (vs. 1 t aluminium ≈ 21.8 t CO2 emitted)
• Hoses and cables routed inside boom for protection
• Engine start/stop from basket
• Independent emergency electric pump with basket controls
• Proportional controls and secure access to working platform
