Multi-voltage DC servo controller MC501

24-48 V

The MC501 is a single axis DC servo controller designed for open-loop operation. It is specifically engineered to drive series 500 and 500MM actuators, making it suitable for precise motion control applications. The MC501 controller uses a wall-mounted DC power supply and is noise-free, allowing it to be used in proximity to sensitive electrophysiology experiments.

Product Features

• Economical DC controller
• Variable, high-resolution speed control
• Preset rapid and medium speed settings
• Variable, slow speed range
• RoHS compliant
• CE compliant

Performance Specifications

• Maximum speed:
• Rapid: 300 µm/second
• Medium: 100 µm/second
• Slow Range / High: 30 µm/second
• Slow Range / Low: 10 µm/second
• Power requirements: 110 VAC, 50/60 Hz

Characteristics / Technical Specifications

• Controller type: Single axis DC servo controller, open loop
• Designed for: Series 500 and 500MM actuators
• Speed settings: Rapid (300 µm/s), Medium (100 µm/s), Slow (variable 30–10 µm/s)
• Power supply: Wall transformer, 24VDC @ 400mA
• Manual/Motorized: Motorized
• Open/Closed Loop: Open loop
• SKU: 71120000E
• Weight UOM: LB
• RoHS and CE compliance
