Pneumatic portable grinder 1 1461 0040

industrialextendablelow-vibration

Product description
The pneumatic axial grinder is designed for grinding applications at speeds up to 10,000 rpm. It delivers high material removal capacity and can be extended with optional extension pieces to reach longer working lengths. The machine is fitted with a tool holder for form grinding bodies (max. Ø 50 mm, M12) suitable for profile and surface grinding in metalworking and mechanical engineering environments.

Main attributes

• Energy source: Pneumatic
• Operating pressure: 6 bar
• Actuation: Twist throttle
• Speed (free): 10,000 rpm
• Tool holder: for form grinding bodies, dia. max. 50 mm, M12

Technical Data (table)
ORDER NO.: 1 1461 0040
Energy source: Pneumatic
Operating pressure: 6 bar
Valve type: Twist throttle
Tool holder for: form grinding bodies, dia. max. 50 mm, M12
Neck dia.: 30.00 mm
Air consumption: 1.50 m³/min
Power: 1.25 kW
Speed (free): 10,000 rpm
Length: 1,010.00 mm
Connection: R1/2" female
Noise level LpA: 88.5 dB(A)
Vibration level: <2.5 m/s²
Weight: 5.0 kg
Fields of application / branch: Metal industry and steel construction; Plant and mechanical construction

Accessories - Extensions (table)
ORDER NO.: 1 1450 7930 | Neck dia. [mm]: 30.00 | Length [mm]: 250.00
ORDER NO.: 1 1450 7940 | Neck dia. [mm]: 30.00 | Length [mm]: 500.00

Miscellaneous Accessories (table)
ORDER NO.: 9 2406 0260 | Service unit (hand-held) with pressure regulator R 3/4" and claw coupling
ORDER NO.: 9 2406 0630 | Service unit with protection housing R 1/2" male
ORDER NO.: 9 3610 0410 | Service unit with protection housing R 1/2" male
ORDER NO.: 9 3610 0420 | Pneumatic hose ID 15 mm, 2.5 m length, complete with claw coupling screwable
ORDER NO.: 9 2101 0010 | Claw coupling, metal sealing, R 1/2" male
ORDER NO.: 9 2102 0020 | Claw coupling, metal sealing, R 1/2" male

Technical specifications

• Order number: 1 1461 0040
• Energy source: Pneumatic
• Operating pressure: 6 bar
• Valve type: Twist throttle
• Tool holder: for form grinding bodies, dia. max. 50 mm, M12
• Neck diameter: 30.00 mm
• Air consumption: 1.50 m³/min
• Power: 1.25 kW
• Free speed: 10,000 rpm
• Length: 1,010.00 mm
• Connection: R1/2" female
• Noise level LpA: 88.5 dB(A)
• Vibration level: <2.5 m/s²
• Weight: 5.0 kg
• Fields of application: Metal industry and steel construction; Plant and mechanical construction
