Resistive touch screen monitor AMG-24IPPC01N1

infrared touchscreenLED backlightLCD

Product overview
The AMG-24IPPC01N1 is a 24-inch panel-mount industrial LCD monitor with multiple signal inputs and optional touchscreen technologies, designed for continuous operation in demanding industrial environments.

Key features

• Support for a wide range of touchscreen technologies (PCAP, resistive, IR, SAW)
• Wide viewing angles (170°H / 160°V)
• Industrial-grade components for reliable 24/7 operation
• LED backlight with effective heat dissipation
• Optional IP-rated front panel and mechanical protection; customization available

Typical applications

• Industrial equipment and HMIs
• Railway and transport control panels

Specification
Model Name: AMG-24IPPC01N1
Screen Size: 24-inch
Active Display Area (mm): 531.36 (H) x 298.89 (V)
Pixel Pitch (mm): 0.27675 (H) x 0.27675 (V)
Display Mode: Normally white
Display Resolution: 1920 x 1080
Contrast Ratio: 1000:1
Display Color: 16.7M colors
Brightness: 300 nits
Backlight: LED
Viewing Angles (CR=10): 170° (H) / 160° (V)
Response Time (Typ. Tr+Tf): 5 ms
Signal Connector: VGA / DVI / HDMI / AV / S-Video / Audio
Power Input: DC 12V
Operating Temperature: 0 ~ 50 °C
Storage Temperature: -20 ~ 60 °C
Relative Humidity: 5% RH ~ 90% RH
Touch Screen: Optional

Characteristics / technical specifications

• Model Name: AMG-24IPPC01N1
• Screen Size: 24-inch
• Active Display Area: 531.36 (H) x 298.89 (V) mm
• Pixel Pitch: 0.27675 (H) x 0.27675 (V) mm
• Display Mode: Normally white
• Resolution: 1920 x 1080 pixels
• Contrast Ratio: 1000:1
• Colors: 16.7M
• Brightness: 300 nits
• Backlight: LED
• Viewing Angles: 170° (H) / 160° (V)
• Response Time: 5 ms (Typ.)
• Interfaces: VGA, DVI, HDMI, AV, S-Video, Audio
• Power Input: DC 12V
• Operating Temp: 0 ~ 50 °C
• Storage Temp: -20 ~ 60 °C
• Relative Humidity: 5% ~ 90% RH
• Touch Screen: Optional
