Radio receiver ACRDIN

wirelessdigitalfor remote control

Description
AUTEC DIN RAIL is a modular receiving unit for installation inside a machine electrical cabinet. It is composed of at least one CPU module and one power supply module. The modular architecture allows up to 4 expansion modules to be added, each able to host up to two optional boards. The unit supports AC/DC power variants and an external antenna. It is installed by hooking the DIN guide onto the rail and is designed to meet stringent vibration requirements. The device provides up to 71 configurable on/off outputs plus START and STOP and supports common industrial interfaces.

Technical data sheet
Power supply: ACRDIN: 24-230 VAC; MVRDIN: 12-24 VDC / 24 VAC
Antenna: external antenna with 1 m, 3 m or 5 m cable length
Number of expansion modules: up to 4
Max number of optional boards: ACRDIN: up to 8; MVRDIN: up to 9
Max number of outputs: 71 on/off + START and STOP
Rated current of STOP / safety outputs: 4 A (250 VAC) / 4 A (30 VDC)
Safety performance of STOP function (EN ISO 13849-1): up to PL e
Protection degree: IP65 (NEMA 4)
Connecting interfaces: terminal blocks
Other connecting interface: 10-pin reduced plug
Dimensions (module): 53.30 x 127.41 x 96.20 mm (2.10 x 5.01 x 3.79 in)
Weights: CPU module 315 g; Expansion module 240 g; Power supply module (ACRDIN) 250 g; Power supply module (MVRDIN) 270 g

Features / technical specifications

• Type: Modular DIN-rail receiver for installation inside a machine electrical cabinet
• Modular composition: at least one CPU module + one power supply module; up to 4 expansion modules; each expansion module can host up to two optional boards
• Power supply options: ACRDIN 24-230 VAC; MVRDIN 12-24 VDC or 24 VAC
• Antenna: external, cable length 1 m / 3 m / 5 m
• Maximum optional boards: ACRDIN up to 8; MVRDIN up to 9
• Maximum configurable outputs: 71 on/off outputs plus START and STOP
• STOP / safety outputs rated current: 4 A (250 VAC) / 4 A (30 VDC)
• Safety level (STOP function) according to EN ISO 13849-1: up to PL e
• Protection class: IP65 (NEMA 4)
• Interfacing: RS-232/485, CANopen, Profibus DP, PROFINET, EtherCAT®, EtherNet/IP™; terminal blocks and 10-pin reduced plug for connections
• Dimensions (module): 53.30 x 127.41 x 96.20 mm (2.10 x 5.01 x 3.79 in)
• Weights: CPU module 315 g; Expansion module 240 g; Power supply module (ACRDIN) 250 g; Power supply module (MVRDIN) 270 g
• Designed for high-vibration environments
