Opto-digital stereo microscope 9-145inspectionfor the electronics industryfor electronic components
Add to favorites
Compare this product
Characteristics
- Type
- opto-digital
- Technical applications
- inspection, for the electronics industry, for electronic components
- Other characteristics
- ergonomic, zoom, digital camera, with full HD digital camera, with wide field of view and long working distance, high-resolution, image capture, USB, with LCD display, image-processing, high-magnification
- Magnification
Max.: 45 unit
Min.: 1.3 unit
- Weight
6,000 g
(211.6 oz)
Description
Product overview
The PCB Inspection Device 9-145 is a high-magnification visual inspection system for printed circuit boards and fine-detail inspection. It combines a high-resolution swiveling camera, a 15.6-inch non-reflective Full HD display and an ergonomic, dust-protected housing for repeated professional use.
Key features
Technical details and additional functions
Specifications
The PCB Inspection Device 9-145 is a high-magnification visual inspection system for printed circuit boards and fine-detail inspection. It combines a high-resolution swiveling camera, a 15.6-inch non-reflective Full HD display and an ergonomic, dust-protected housing for repeated professional use.
Key features
- Magnification: 1.3x–45x (optical-digital zoom)
- Large field of view: 265 mm (suitable for 15.6-inch format)
- Photo function with storage on inserted SD card (can be disabled)
- USB Type-C interface for data transfer
- 15.6-inch non-reflective LCD-TFT display, Full HD
- Integrated autofocus (user-switchable)
- Customizable, user-friendly menu and switchable voice guidance
- Included: USB Type-C cable, 8 GB SD card, universal charger
- Weight: approx. 6000 g
Technical details and additional functions
- High-resolution camera with optical-digital zoom producing true-color Full HD images
- Fast autofocus optimized for reading; autofocus can be switched off to improve visibility of markings
- Powerful LED illumination optimized for the 265 mm field of view
- Switchable optical orientation aids (reading line / overview display)
- Easy-to-understand voice output for menu navigation (can be disabled)
- 14 contrast-enhanced false color/image modes
- Swiveling camera and protective camera cover for dust and dirt protection
- Device supports independent software updates and factory reset
Specifications
- Model designation: 9-145
- Magnification: 1.3x – 45x (optical-digital zoom)
- Field of view: 265 mm (15.6-inch format)
- Display: 15.6-inch non-reflective LCD-TFT, Full HD
- Camera: high-resolution, swiveling
- Autofocus: integrated, very fast; on/off
- Illumination: integrated powerful LEDs
- Image modes: 14 false color / contrast-enhanced modes
- Photo function: save to SD card (8 GB included); function can be disabled
- Interfaces: USB Type-C
- Included accessories: USB Type-C cable, 8 GB SD card, universal charger
- Weight: approx. 6000 g
- Maintenance: supports software updates and resets; camera cover for dust protection
