Digital video microscope 9-146inspectionindustrialfor the electronics industry
Add to favorites
Compare this product
Characteristics
- Type
- digital
- Technical applications
- inspection, industrial, for the electronics industry, for electronic components
- Configuration
- benchtop
- Light source
- LED illumination
- Other characteristics
- zoom, high-resolution, USB, with LCD display, digital camera, with full HD digital camera, image capture, ergonomic, image-processing, sliding-stage
- Magnification
Max.: 45 unit
Min.: 1.3 unit
- Weight
6,300 g
(222.2 oz)
Description
Application
The 9-146 PCB inspection device with XY-table is a high-resolution visual inspection system designed for precise examination of printed circuit boards. It combines a large 265 mm viewing area with a wide optical magnification range and a 15.6-inch non-reflective Full HD display. Integrated, user-switchable autofocus, fast focusing and powerful LED illumination support detailed inspection tasks. Data transfer is available via USB Type-C and images can be stored on an SD card.
Key features
Technical specifications
The 9-146 PCB inspection device with XY-table is a high-resolution visual inspection system designed for precise examination of printed circuit boards. It combines a large 265 mm viewing area with a wide optical magnification range and a 15.6-inch non-reflective Full HD display. Integrated, user-switchable autofocus, fast focusing and powerful LED illumination support detailed inspection tasks. Data transfer is available via USB Type-C and images can be stored on an SD card.
Key features
- Optical magnification range: 1.3× – 45×
- Large 265 mm field of view (15.6-inch format)
- Photo capture with SD card storage (8 GB SD card included)
- USB Type-C connection for data transfer
- Non-reflective 15.6" LCD-TFT display, Full HD true-color image
- Integrated autofocus (switchable on/off)
- Very fast autofocus for comfortable reading and inspection
- Powerful LED illumination covering the full 265 mm viewing area
- Swiveling camera with protective camera cover
- Switchable optical orientation aids (reading line / overview display)
- Voice output of menu steps (switchable)
- 14 contrast-enhanced false color modes
- User-friendly menu with customizable settings
- Stable, ergonomic design suitable for industrial use
Technical specifications
- Commercial designation: PCB Inspection Device with XY-table (model 9-146)
- Magnification range: 1.3× – 45×
- Field of view: 265 mm
- Display: 15.6" non-reflective LCD-TFT, Full HD resolution
- Camera: high-resolution camera with optical-digital zoom; swiveling camera
- Autofocus: very fast, switchable on/off
- Illumination: powerful LED illumination
- Image modes: 14 contrast-enhanced false color modes
- Photo storage: SD card (8 GB SD card included)
- Connections: USB Type-C for data transfer
- Power: universal charger for worldwide use (included)
- Accessories included: USB Type-C cable, 8 GB SD card, universal charger, camera cover
- Weight: approx. 6300 g
- Software: independent execution of software updates and resets
