Angle grinder adapter 9-255-ESD

aluminium

Product overview

Features

• 360° rotatable precision ball joint, steplessly lockable with quick-release clamp; Made in Germany
• Extends the turning circle of the ball; can be screwed onto all ball joint holders
• Smooth adjusting screw for quick tightening and loosening
• Designed for combination with board holder 9-253-ESD; suitable for 9-251-ESD
• Cast aluminium with black ESD powder coating; dissipative surface with surface resistance 10^7 to 10^8 ohm
• Weight: 95 g

Area of application
Accessory or replacement for ball joint vice 9-251-ESD. Suitable for use in electrostatically protected areas (ESD workplace / ESD protection zone).

Technical description
EPA suitable. The ESD version features a dissipative black surface with a resistance between 10^7 and 10^8 ohm. The base can be connected to the earthing point using a 10 mm push button.

Technical specifications

• Article number: 9-255-ESD
• Model name: SPANNFIX
• Mounting thread: M12 x 1.5 (for screwing on)
• Material: Cast aluminium
• Surface finish: Black ESD powder coating (dissipative)
• Surface resistance: 10^7 to 10^8 ohm
• Rotation: 360° (steplessly lockable)
• Adjustment: Smooth adjusting screw for quick tightening/loosening
• Compatibility: For use with ball joint holders; combinable with board holder 9-253-ESD; suitable for 9-251-ESD
• Earthing: Base can be connected to earthing point via 10 mm push button
• Weight: 95 g
• Intended use: EPA / ESD workplace
