Visualization software - DAQ - SENECA | AUTOMATION INTERFACES - report management / monitoring / simulation

Characteristics

Function: visualization, report management, monitoring, simulation, communications, scheduling, measurement, calibration, for test, reporting, configuration, data acquisition, storage, OPC server
Applications: process, network, alarm, Ethernet, TCP
Type: real-time
Operating system: Windows
Other characteristics: slave

Description

Data Recorder 2.0 is an open, scalable, and affordable Windows PC-based software. A solution designed for professionals, maintainers, students, researchers, designers, and technical managers active in test, measurement, simulation, and testing sessions. Data Recorder 2.0 supports SENECA I/O modules, power meters, and third-party ModBUS RTU slave devices through serial (RS232/RS485/ModBUS RTU) or Ethernet/ModBUS TCP communications. You can also use the software in networks with distributed I/O by using radio modems or by using access points and Wi-Fi devices. The software includes a free, unlimited user license for up to 2 channels with PLUS functions that can be integrated with multi-channel licenses as required. Main features: - Manual/event/scheduled data recording - Real-time data logging in pen or display mode - Historical data/data display via Trend Viewer - Data storage in CSV, OPC server, SQLite format - Advanced calibration for temperature sensors - Alarm functions with DO management - Automatic report management at the end of the session - Advanced mathematical functions - Multi-session/Multi-DB on the same PC (PLUS licenses)
