HMI with touch screen VISUAL6E

resistive touch screenpanel-mount800 x 480

7" HMI panel touchscreen with 2 ETH ports SENECA expands its offer for the Z-PC with VISUAL, the new range of operator panels suitable for the most common industrial controllers and supervisory/automation systems. - Size: 7’ TFT LCD - Resolution: 800x480 - Format: 16:9 - Brightness: 400 cd/m2 - Contrast: 800:1 - Retroillumination: LED > 30,000 hours - Colours: 16.7 million - Touchscreen: 4-wire, resistive - Precision: ±2% COMMUNICATION - USB Host 2.0: 1 - Ethernet 10/100: 2 - RS232: 1 - RS485: 1 GENERAL DATA - Flash: 4 GB - RAM: 1 GB - Processor: Quad Core RISC - RTC: Integrated - Power supply: 24 Vdc - Absorption: 820 mA @ 24 Vdc - Casing: Plastic - Dimensions (lxhxp): 200.3 x 146.3 x 34 mm - Hole dimensions: 192 x 138 mm - Weight: 600 g - Operating temperature: 0..55°C - Grade of protection: NEMA4 / IP66 - Fanless: Yes - Certification: CE, UL CONFIGURATION AND PROGRAMMING - EASY BUILDER PRO: Yes - EASY ACCESS: Yes - Dashboard: Yes - CODESYS: Yes Shipping and Export Information - PRODUCT CODE: VISUAL6E - GROSS WEIGHT (kg): 0.86 - ORIGIN: TW - CN (Combined Nomenclature): 85312040 - ECCN: 4A994 - Mandatory accessory: RS485 serial cable (DB9M / test leads) for connection with VISUAL HMI with DB9F socket (CS-DB9M-TIP-V) - Mandatory accessory: Ethernet cable (right) ( RJ45 / RJ45 ) (CE-RJ45-RJ45-R | PM001450) Technical Specifications / Features - 7” TFT LCD touchscreen, 800x480 resolution, 16:9 format - Brightness: 400 cd/m2, Contrast: 800:1 - LED backlight > 30,000 hours - 16.7 million colors - 4-wire resistive touchscreen, ±2% precision - 1x USB Host 2.0, 2x Ethernet 10/100, 1x RS232, 1x RS485 - 4 GB Flash, 1 GB RAM, Quad Core RISC processor - Integrated RTC - Power supply: 24 Vdc, Absorption: 820 mA @ 24 Vdc - Plastic casing, Dimensions: 200.3 x 146.3 x 34 mm, Hole: 192 x 138 mm - Weight: 600 g (gross 0.86 kg) - Operating temperature: 0..55°C - Protection: NEMA4 / IP66, Fanless - Certifications: CE, UL - Configuration/Programming: EASY BUILDER PRO, EASY ACCESS, Dashboard, CODESYS - Origin: Taiwan (TW) - CN code: 85312040, ECCN: 4A994
