Resistive touch screen HMI VISUAL11E

panel-mount1024 x 768RISC

Product: VISUAL11E Subtitle: 9.7" HMI panel touchscreen with 2 Ethernet ports and isolated serial ports RS232, RS485 SENECA expands its offer for the Z-PC with VISUAL, the new range of operator panels suitable for the most common industrial controllers and supervisory/automation systems. - Size: 9.7’ TFT - Resolution: 1024x768 - Format: 4:3 - Brightness: 350 cd/m2 - Contrast: 900:1 - Retroillumination: LED > 30,000 hours - Colours: 262 k - Touchscreen: 4 wires, resistive - Precision: ±2% COMMUNICATION - USB Host 2.0: 1 - Ethernet 10/100: 1 - Ethernet 10/100/1000: 1 - RS232: 1 - RS485: 1 - CAN bus support: Yes - Wi-Fi: Optional GENERAL DATA - Flash: 4 GB - RAM: 1 GB - Processor: Quad Core RISC - RTC: Integrated - Power supply: 24 Vdc - Absorption: 1A@24Vdc - Casing: Plastic - Dimensions (lxhxp): 260.6 x 203.1 x 36.5 mm - Hole dimensions: 250 x 192 mm - Weight: 1000 g - Operating temperature: 0..50°C - Grade of protection: UL Type4X / NEMA4 / IP66 - Fanless: Yes - Certification: CE, UL CONFIGURATION AND PROGRAMMING - EASY BUILDER PRO: Yes - EASY ACCESS: Optional - Dashboard: Optional - CODESYS: Optional Shipping and Export Information - PRODUCT CODE: VISUAL11E - GROSS WEIGHT (kg): 0.87 - ORIGIN: TW - CN (Combined Nomenclature): 85312040 - ECCN: 4A994 Mandatory Accessories - CS-DB9M-TIP-V: RS485 serial cable (DB9M / test leads) for connection with VISUAL HMI with DB9F socket - CE-RJ45-RJ45-R | PM001450: Ethernet cable (right) ( RJ45 / RJ45 ) Technical Features / Specifications - 9.7” TFT display, 1024x768 resolution, 4:3 format - 350 cd/m2 brightness, 900:1 contrast, LED backlight > 30,000 hours - 262k colors, 4-wire resistive touchscreen, ±2% precision - 1x USB Host 2.0, 2x Ethernet (10/100 and 10/100/1000), 1x RS232, 1x RS485, CAN bus support, optional Wi-Fi - 4 GB Flash, 1 GB RAM, Quad Core RISC processor, integrated RTC - 24 Vdc power supply, 1A@24Vdc absorption - Plastic casing, 260.6 x 203.1 x 36.5 mm dimensions, 250 x 192 mm hole dimensions, 1000 g weight - Operating temperature: 0..50°C - Protection: UL Type4X / NEMA4 / IP66, fanless design - Certifications: CE, UL - Configuration/programming: EASY BUILDER PRO (yes), EASY ACCESS (optional), Dashboard (optional), CODESYS (optional)
