Pneumatic calibration pump ADT 920

manuallow-pressurefor pressure and vacuum

Presentation
The pneumatic pump ADT 920 ADDITEL is a manual calibration pump designed to generate and control pressure up to 200 bar (3000 psi). A fine-adjustment screw enables pressure setting down to 0.1 mbar. The pump uses a shut-off valve to ensure high stability and reduced maintenance. It includes a liquid isolation chamber with drain to purge traces of liquids from the air. Two hand-tight connections allow connection and disconnection of gauges without PTFE tape or wrenches. It is suitable for high-pressure pneumatic applications and for calibrating transmitters and pressure gauges in the field or in the laboratory.

Key features

• Generates and controls pressure up to 200 bar (3000 psi).
• Fine pressure adjustment: 0.1 mbar.
• Shut-off valve for excellent stability.
• Drainable liquid isolator to purge liquid traces.
• Hand-tight connections for tool-free gauge connection/disconnection.
• Designed for laboratory calibrations and on-site interventions.

Models and pressure connections

• Main model: ADT920 — low-pressure pneumatic pump, -0.95 to 200 bar.
• Available pressure ports: N: 1/4 NPT female; N2: 1/2 NPT female; B: 1/4 BSP female; M: M20×1.5 female.

Accessories (included and optional)

• Standard accessories included: 20 O-rings, user manual.
• Optional accessories: ADT102 (1/4 NPT male adapters to various hand-tight female connections, 25 pcs), ADT103 (1/4 NPT male adapters to various hand-tight female connections, 10 pcs), ADT100-HTK (1.5 m test hose kit, 1000 bar psi, 1/4 NPT male to various hand-tight female models), 9909-920 (carrying case for ADT 920 and 2 gauges), ADT920-MK (maintenance kit for 920 pump).

Specifications / technical data

• Medium: Air.
• Pressure range: 95% vacuum to 200 bar (-0.95 to 200 bar / -14 to 3000 psi).
• Pressure generation: 0 to 200 bar in 40 seconds.
• Fine adjustment: 0.1 mbar.
• Materials and components: stainless steel adapters; body in stainless steel/aluminium/copper; Buna-N seals.
• Manifold: dissolved-liquid collector in gases with manual drain.
• Device under test connection: 1/4 NPT female, 1/4 BSP female, or M20×1.5 female.
• Reference connection: 1/4 NPT female, 1/4 BSP female, or M20×1.5 female.
• Dimensions: height 178 mm; base 540 mm x 270 mm.
• Weight: 6.5 kg.
• Warranty: 1 year.
