High-frequency ultrasonic transducer BBDM-80KR4M

for level measurementfor obstacle detectionmeasurement

Overview
The BBDM-80KR4M is an 80 kHz air ultrasonic distance transducer engineered for short-range detection and proximity measurement. Reference detection range is 0.2 to 4 m. Typical industrial applications include proximity sensing for automation, short-range positioning, counting/target detection and compact level measurement.

Acoustic field and configurations
The product is available in two acoustic configurations with different -3 dB half-power angles. The standard configuration has a -3 dB angle of 13.4° ±10%. The M38 x 1.5 threaded configuration provides a -3 dB angle of 11.5° ±10%. Choose the acoustic field to minimise competing echoes from nearby guides, frames or guards.

Core specifications
Model: BBDM-80KR4M
Center frequency: 80 kHz ±5%
Reference range: 0.2–4 m
Minimum impedance: 400 Ω ±20%
Capacitance: 1,100 pF ±20% at 1 kHz
Operating voltage: Peak voltage below 1,500 Vpp
Operating temperature: -40 to +80 °C
Pressure rating: Up to 3 kgf / 0.3 MPa
Housing material: Brass
Protection rating: IP68
Weight: 225 g ±5% (with 2 m cable)

Available acoustic configurations
Center frequency: 80 kHz ±5% — Reference range: 0.2–4 m — -3 dB half-power angle: 13.4° ±10% (standard)
Center frequency: 80 kHz ±5% — Reference range: 0.2–4 m — -3 dB half-power angle: 11.5° ±10% (M38 x 1.5 thread)

Electrical and environmental integration
Drive and receive stages must match the minimum impedance (400 Ω) and the capacitance (1,100 pF at 1 kHz). Peak excitation must remain below 1,500 Vpp. Specified cable length is 2 m. Operating temperature range is -40 to +80 °C. Pressure limit is 3 kgf / 0.3 MPa. Protection rating is IP68.

Operational guidance
For counting or proximity detection, target size, surface condition and orientation affect return signal strength. Nearby structures can create competing echoes within the acoustic field. For short-range positioning keep the travel within the 0.2–4 m reference interval. For compact level installations maintain a clear acoustic path through the vessel opening and away from internal fittings.

Technical specifications

• Model: BBDM-80KR4M
• Center frequency: 80 kHz ±5%
• Reference range: 0.2–4 m
• -3 dB half-power angle: 13.4° ±10% (standard)
• -3 dB half-power angle: 11.5° ±10% (M38 x 1.5 thread)
• Minimum impedance: 400 Ω ±20%
• Capacitance: 1,100 pF ±20% at 1 kHz
• Operating voltage: Peak < 1,500 Vpp
• Operating temperature: -40 to +80 °C
• Pressure rating: up to 3 kgf / 0.3 MPa
• Housing material: Brass
• Protection rating: IP68
• Weight: 225 g ±5% (with 2 m cable)
• Cable length: 2 m
